₹43.42 (Including tax)
Discount per Bulk Quantity
Quantity | Discount | Price |
---|---|---|
5 - 10 | 5% | ₹41.26 (Including tax) |
11 - 20 | 8% | ₹39.96 (Including tax) |
21 - 40 | 10% | ₹39.08 (Including tax) |
41 - 100 | 12% | ₹38.20 (Including tax) |
Out of stock
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Get the Priority Shipping on Prepaid Orders
Prepaid Orders
Get Normal Delivery (Surface) with Cash On Delivery
COD Orders
BMS (Battery Management System) – a battery management system that is designed to monitor the status of batteries, control the process of charging/discharging the battery, etc.
This BMS module has protection against short circuits, overcharges and over-discharge. One of the functions of the charge controller is to turn off the power supply for the batteries when the maximum capacity of at least one battery is reached. This BMS controller is designed for more than 30,000 hours of operation. The maximum allowable current is 3A.
If the maximum permissible value of the supply voltage is exceeded, the charge controller activates the “protection” mode. In order to restore the module, it is necessary to re-apply voltage to the input of the BMS board or wait a while until the charge controller automatically disables protection.
1 x 1S 3A 18650 Lithium Battery Protection Board
Charging voltage |
3.7V |
---|---|
Overcharge Detection Voltage |
4.25 ± 0.05V |
Overcharge release voltage |
4.23 ± 0.05V |
Over discharge detection voltage |
2.45 ± 0.1V |
Upper Limit Continuous Current |
5A |
Overcurrent Detection Current |
7A Width (mm): 4.2 Height (mm): 2 Weight (gm): 3 Shipment Weight: 0.005 kg Shipment Dimensions: 3 × 3 × 1 cm |
Length (mm) |
35.15 |
Width (mm) |
4.2 |
Height (mm) |
2.4 |
Weight (gm) |
3 |
Only logged in customers who have purchased this product may leave a review.
Shipping and Delivery Policy
1. Shipping Process:
2. Shipping Charges:
3. Order Tracking:
4. Delivery Address:
5. Delivery Issues:
6. No Return Policy for Opened/Soldered Products:
7. Refund Policy:
Out of stock
Model |
18650 |
---|---|
Product Type |
Li-ion BMS |
Charging Current |
2A-9A |
Charging Voltage |
3.7V |
Overcharge Detection voltage |
3.7±0.05V |
Overcharge protection delay |
IS |
Overcharge release voltage |
3.7±0.05V |
Over-discharge detection voltage |
2.0-2.1V |
Over-discharge detection delay |
100mS |
Over discharge release voltage |
2.3±2.1V |
Dimension |
9x1x1 cm |
Weight (g) |
5g |
Out of stock
Model |
Li-ion 18650 |
---|---|
Product Type |
Li-ion BMS |
Over-current detection current |
7.5 A |
Charging voltage |
4.2V |
Maximum sustained current |
6A |
A discharge detection voltage |
2.45 + / – 0.1 V |
Charging |
release of the 4.23 + / – 0.05 V |
Charging test voltage |
4.25 + / – 0.05 V |
Dimensional Accuracy (mm) |
35 x 7.4 x 7.4 |
Out of stock
Out of stock
In stock
Out of stock
For Li-Po LiMnO Protect Parameter |
3.6V/3.7V |
---|---|
Single-cell battery overcharge protect voltage |
4.21-4.29 V |
Single-cell battery overcharge protects recover voltage: |
4.14-4.24 V |
Overcharge protect delay |
1.5-2.5S |
Single cell battery over-discharge protect voltage |
2.72-2.88 V |
Single cell battery over-discharge protect recover voltage |
2.9-3.1 V |
Over charge protective current |
100A |
Over discharge protective current |
100A |
Over-discharge protect delay |
0.5-1.5S |
Temperature protection |
Yes ,have a Temperature control interface. |
Disconnect protect |
Yes |
Shortage delay |
100-600 uS |
Contact discharge current |
80A |
Syncline discharge current |
60A |
Charging current |
60A |
Ampere balance (Current) |
60MA |
