Chipsee EPC-A72-70-C Industrial embedded 7 Inch PC

15 People watching this product now!

SKU: rz24310728 Category: Single Board Computer

Description

This product features the Rockchip RK3399, an ARM dual Cortex-A72 (1.8GHz) plus Quad Cortex-A53 (1.4GHz) high performance and ultra-efficient processor that implements the ARM v8-A architecture. The fast processing of Cortex-A72 is particularly suited to mobile applications

Capacitive touch screen PCs have a unique mechanical design, unified from the shape and fixed connection, ensuring seamless integration of hardware. Besides, our manufacturing technologies offer the possibility of changing the display sizes of the system, upgrading computing performance, and I/O connections. The performance of our capacitive touch panel PC is depending entirely on the needs of customers’ applications

Applications:

Mobile Applications
Video Processing
Machine Learning
Video Gaming
Process Control
Process Monitoring
ATM

Features:

This product comes with a pre-installed Android 7.1 or Debian 10
high performance and ultra-efficient processor
The fast processing of Cortex-A72 is particularly suited to mobile applications
They are also very durable and resistant to environmental contaminants like dust and water
Five-point capacitive touchscreens offer stable and accurate control over the device.
Installation on an industrial cabinet
Integration with the existing equipment

Specifications:

CPU: Rockchip RK3399
RAM: 4GB DDR3
External storage: TF (MicroSD) Card Slot
FLASH: 16GB
Resolution: 1024 X 600
Brightness (NIT): 500 NIT
Touch Screen: Capacitive
Bluetooth: Onboard Bluetooth
WiFi: Onboard WiFi
HDMI: 1x HDMI
Ethernet: 1x LAN 1000M
USB: 1x USB 3.0 HOST, 1x USB Type-C, 1x USB 2.0 HOST
GPIO: 8x GPIO
RS232+RS485: Default 4xRS232 and 2x RS485 (1 debug port)
Buzzer: Yes
Power Consumption: 8W
Power Input: 12~36V DC
Working Temperature: -20°C ~ 70°C.a
Mounting Method: Embedded Mounting
Preinstalled OS : Android 7.1, Debian 10
Form-factor: Embedded
Display Size (inch.): 7.0″
Weight 345 g
Dimensions: 190 × 107 × 27.7 mm

Packages Includes:

1 x Chipsee EPC-A72-70-C Industrial embedded 7 Inch PC
