Degson 2 Pin 5.0mm Pitch Pluggable Terminal Block

The Degson DG332W-5.0-02P is a pluggable terminal block used for connecting wires to a printed circuit board or another device. It is designed for a rated current of 12A and a rated voltage of 250V.

The terminal block features a pitch of 5.0mm, which refers to the distance between the centers of adjacent pins. It has a screw connector with wire protection, which means that wires are secured by tightening the screws on the connector to make a secure electrical connection. The wire protection feature ensures that the wires do not come loose or pull out of the connector.

The cross-section of the wire that can be connected to the terminal block is 1.5mm², which refers to the area of the wire’s cross-section. The connector has a green color, which can be used to identify the specific circuit or function that it is connected to.

Specifications and Features:

1. Number of Pins: 2
2. Pitch: 5.0mm
3. Rated voltage: 250V
4. Rated current: 12A
5. Wire gauge: 26-16 AWG
6. Insulation material: PA66, UL94V-0
7. Contact plating: Tin
8. Operating temperature: -40°C to +105°C (-40°F to +221°F)
9. Wire connection method: Screw connection with wire protection
10. Color: Green

Package Includes:

1 x Degson 2 Pin 5.0mm Pitch Pluggable Terminal Block
