GBPC3510W 1000V, 35A Single Phase Bridge Rectifier

Original price was: ₹95.00.Current price is: ₹80.07. (Including tax)

Discount per Bulk Quantity

QuantityDiscountPrice
5 - 105%76.06 (Including tax)
11 - 208%73.66 (Including tax)
21 - 4010%72.07 (Including tax)
41 - 10012%70.45 (Including tax)

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

  • fast delivery Fast Shipping

    Get the Priority Shipping on Prepaid Orders

Prepaid Orders

  • normal shipping Normal Shipping

    Get Normal Delivery (Surface) with Cash On Delivery

COD Orders

16 People watching this product now!
Description

The GBPC3510W  is  a Single Phase Bridge Rectifier .The maximum input AC RMS voltage of this IC is 700V hence can be used for a broad range of applications. The maximum average current this IC can handle is around  35A. This IC has a reverse breakdown voltage of 1000V and a low forward voltage drop of 1.2V. It has high efficiency and a  surge current capability of 400 A. If you are looking for a compact IC for rectification application this can be a good choice. This single phase bridge rectifier is mainly used in charger circuits , uninterruptible power supply , led and lcd TVs, audio amplifier and radios.

Features

  • High thermal conductivity package, electrically insulated case
  • Positive polarity symbol moulded on the plastic case
  • Centre hole fixing
  • Glass passivated diode chips
  • Excellent power/volume ratio
  • -55 to 150°C Operating junction temperature range
  • Specification
    ModelGBPC3510W
    TypeBridge Rectifier Diode
    Working Peak Reverse Voltage1000 V
    RMS Reverse Voltage VR(RMS)  700 V
    Average Forward Rectified Output Current35A
    Peak Reverse Current at 25°C10µA
    No. of Pins4Pins
    Operating and Storage Temperature Range-55°C TO 150°C
    Country of OriginChina
