NY-D01 100A Digital Display Spot Welding Controller Board

SKU: rz24317381
In Stock

1,483.00

  1. Material: Plastic+Metal
  2. The controller is compatible with 100A scr.
  3. Digital control interface, you can display the current time and current settings.
  4. Time input 1-50, unit cycle (1 cycles is 20ms)
In Stock
Add to Wishlist
Add to Wishlist

Did you like this product? Add to favorites now and follow the product.

Add to Wishlist
Add to Wishlist
Have a Question? Ask a Specialist

+91-7231900002 Connect on Whatsapp

Low Prices

Price match guarantee

Guaranteed Fitment.

Always the correct part

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Description

The principle of silicon controlled phase shifting triggering is adopted to adjust the time and the current to achieve welding. With a digital display, you can directly see the time and current. Optocoupler isolates the strong and weak electricity, making the operation safer. Using a high-precision single potentiometer to ensure reliable and convenient input. The design of a reliable zero-crossing detection circuit ensures the SCR phase shift accuracy. Made of high-quality PCB, the control board is long-lasting. The module is 8cm long, 6cm wide and 2cm high. It is developed for DIY or simple resistance welding.


Features:

1 The use of STM8 industrial control center microcontroller.
2 Strong and weak electricity through optocoupler insulation, safe operation.
3 The power line and foot switch line adopts the bolt the quick connect terminal, more convenient and reliable.
4 Input time, current using a high-precision simple potentiometer, to ensure reliable, convenient input
5 On-board power supply, state, foot, trigger indicator, work status clearly visible.
6 The design of reliable zero-crossing detection circuit to ensure that the SCR phase shift accuracy.
7 The controller is compatible with 100A scr.
8 Digital control interface, you can display the current time and current settings.
9 Input time of 1-50, cycle unit (1 cycles is 20 ms), current input (30-99%),

Specification:

  1. Material: Plastic+Metal
  2. The controller is compatible with 100A scr.
  3. Digital control interface, you can display the current time and current settings.
  4. Time input 1-50, unit cycle (1 cycles is 20ms)

Package Includes:

1 x NY-D01 100A Digital Display Spot Welding Controller Board
