Product details
T93YA501KT20
Trimpot, Multi-Turn, Cermet, Top Adjust, 500 ohms, Through Hole, 23 Turns
The T93 is a small size trimmer – 3/8″ x 3×8″ x 3/16″ – answering PC board mounting requirements. Five versions are available which differ by the position of the control screw in relation to the PC board plane and by the spacing of the terminals. Excellent operational stability is provided by the use of a cermet element.
- Industrial grade
- 21 turns Electrical travel
- 23 turns Mechanical travel
- Fully sealed – IP67
- Operating temperature range -55°C to +125°C
- Resistance value range: 10 R to 2.2MR
Specifications:
- Track Resistance: 500ohm
- Trimpot Type: Multi-Turn
- No. of Turns: 23Turns
- Element Material: Cermet
- Adjustment Type: Top Adjust
- Power Rating: 500mW
- Potentiometer Mounting: Through Hole
- Product Range: T93
- Resistance Tolerance: ± 10%
- Temperature Coefficient: ± 100ppm/°C
- Trimpot Shape / Size: 3/8 Inch Square
Package Includes:
1 x T93YA501KT20-Trimpot Potentiometer
