BG120-10-A-0-N-D-RECEPTACLE, BOARD TO BOARD, 2R

0 Reviews
Available on backorder

97.75 (Excluding tax)

  1. Connector Systems: Board-to-Board
  2. Pitch Spacing: 2.54mm
  3. No. of Rows: 2Rows
  4. No. of Contacts: 10Contacts

Discount per Bulk Quantity

QuantityDiscountPrice
5 - 105%92.86 (Excluding tax)
11 - 208%89.93 (Excluding tax)
21 - 4010%87.98 (Excluding tax)
41 - 10012%86.02 (Excluding tax)
  • Estimated delivery time 2-4 days
  • (Subject to stock Availability)
SKU: rz2434924

Product details

The BG120-10-A-0-N-D is a 10-contact 2.54mm black straight Board-to-board Socket with gold flash (standard) plated phosphor bronze contacts and a UL94V-0 polyamide nylon 6T standard insulator. The BG120 series receptacle has tuning fork type contacts, surface type PCB mount, and dual entry type. LCP and Nylon 6T are suitable for IR reflow, wave and manual solder.


Features:

  1. No locating peg
  2. 3A Current rating
  3. 20mR Maximum contact resistance
  4. 1000MR Minimum insulation resistance
  5. 600VAC Dielectric withstanding voltage
  6. 0.64mm Mates with square pin size

Specifications:

  1. Connector Systems: Board-to-Board
  2. Pitch Spacing: 2.54mm
  3. No. of Rows: 2Rows
  4. No. of Contacts: 10Contacts
  5. Connector Mounting: Surface Mount
  6. Product Range: BG120
  7. Contact Material: Phosphor Bronze
  8. Contact Plating: Gold Plated Contacts

Package Includes:

1 x G120-10-A-0-N-D-RECEPTACLE, BOARD TO BOARD, 2R
