DFRobot Indoor ENS160 Air Quality Sensor &#8211; I2C

18 People watching this product now!

SKU: rz2438092 Category: Gas and Dust Sensor

Description

This ENS160 Air Quality Sensor (I2C), based on ScioSense’s new ENS160 sensor chip, is specifically designed for indoor air quality monitoring and offers detection of multiple IAQ data (TVOC, eCO2, AQI). The combination of the innovative TrueVOC™ technology and the metal oxide (MOX) technology brings this sensor superior accuracy, fast response, anti-interference, etc.

With intelligent on-chip algorithms, the ENS160 can directly output rich and easy-to-understand environmental data. Preheat the sensor 3 minutes before use to obtain accurate data more quickly. What’s more, the built-in automatic baseline correction algorithm ensures the long-term stability of the sensor.

Features:

The probe shape makes installation easier
Multiple IAQ outputs (TVOC, eCO2, AQI), various environmental data
Less than 3 minutes warm-up time, get data faster
Built-in algorithm, more accurate output
Automatic baseline correction, more stable for long-term use

Specifications:

Supply Voltage: 3.3V~5V
Operating Current: 29mA
Preheat Time: ＜3 minutes
Communication Mode: I2C
I2C Address: 0x53
Operating Temperature: -10℃~80℃
Operating Humidity: 5%RH~95%RH (Non-condensing)
eCO2 Detection Range: 400ppm~65000ppm
TVOC Detection Range: 0ppb~65000ppb
Cable Length: 1m

Package Includes:

1 x DFRobot Indoor ENS160 Air Quality Sensor – I2C
