1. It has a type-c USB.
2. Support cloud server development /SDK for user firmware development.

Package Includes:

1 x Downloader Expansion Board for TTGO T-Internet- POE

Industrial Grade Multifunctional USB HUB, Extending 3x USB Ports + 100M Ethernet Port

Features:

1. 3x extended USB ports, compatible with USB 2.0 / 1.1
2. Onboard RTL8152B Ethernet chip, adapting RJ45 network port, 10/100M adaptive
3. Industrial grade HUB chip, adopting STT technology, allows stable and smooth concurrent USB connections
4. ESD protection for each USB port, preventing electric surge damage and data loss
5. Onboard large-capacity electrolytic capacitor, effectively making the power supply output of the USB port more stable
6. Over-voltage protection, effectively preventing other high-voltage power inputs from damaging the connected devices
7. Multiple protection circuits: over-voltage, over-current, short circuit, over-temperature, reverse current, under voltage lock-out, 8KV ESD protection, filtering protection, etc.
8. LED indicators for monitoring operating statuses of power supply, network port, and USB ports
9. Industrial grade metal case, rugged & durable, with mounting holes for easy installation

Specifications:

1. USB Port USB 2.0 Port x 3, theoretically up to 480Mbps
2. Networking: 10/100 adaptive
3. USB hub Input: operating voltage: 5V
4. Connector: USB-B
5. USB Output Operating Voltage: 5V@Imax:1.2A①
6. Connector: USB-A
7. External Power: power supply voltage DC 5V②
8. connector: DC jack
9. Operating Environment: -40℃ ~ 85℃
10. OS Support: Mac OS (8.6 or above), Linux(2.4.20 or above), Windows 11 / 10 / 8.1 / 8 / 7 / XP

Package Includes:

1 x Waveshare Industrial Grade Multifunctional USB HUB, Extending 3x USB ports + 100M Ethernet Port

Industrial Serial Server, RS232 To RJ45 Ethernet, TCP/IP To Serial, Rail-Mount Support, With POE Function(Optional)

Features:

1.  It combines multi functions in one  including serial server, Modbus gateway, MQTT gateway, RS232 to JSON, etc
2. The module features RS232 and Ethernet port(POE function is optional)
3. The rail-mount case design, small in size, easy to install
4. It is suitable for applications like data acquisition, IoT gateway, safety & security IoT, and intelligent instrument monitoring

Specifications:

1. Product Type: Serial server, Modbus Gateway, MQTT Gateway
2. Basic Function: Bi-directional transparent data transmission between RS232 and Ethernet
3. Communication interface: RS232 port x 1, Ethernet port x 1
4. Power supply: 6 ~ 36V DC screw terminal 6 ~ 36V DC screw terminal, or PoE port
5. Isolation Protection: Power isolation, Signal isolationEthernet common network port PoE network port, support IEEE 802.3af standard
6. 10 / 100M auto-negotiation RJ45 connector, 2 KV surge protection
7. Serial port: Isolated RS232
8. Baudrate 300 ~ 115200 bps
9. Parity bit none, odd, even, mark, space
10. Data bit: 5 ~ 9 bits
11. Flow control: N/A
12. Protocol: ETHERNET, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS
13. Configuration: host, web browser, device management functions library
14. Communication method: TCP/IP direct communication, VCOM
15. Operating mode: TCP server, TCP client (coexisting with TCP server), UDP, UDP multicast

Package Includes:

1 x Waveshare Industrial serial server, RS232 to RJ45 Ethernet, TCP/IP to serial, rail-mount support, with POE function

Dual ETH Mini-Computer For Raspberry Pi Compute Module 4(NOT Included), Gigabit Ethernet, 4CH Isolated RS485, USB2.0.CM4-ETH-RS485-BASE-B, which is an expansion board that can be used with Raspberry Pi Compute Module 4, and supports 7-36V DC power supply and 5V DC DC power supply of Type -C interface. Onboard four isolated RS485 interfaces, 100M+1000M dual network ports, HDMI interface, two CSI interfaces and two USB interfaces, etc

Note: Raspberry Pi Compute Module 4(NOT Included)

Features:

1. Cooling Fan Included
2. Precise Cut-Out With Clear Label
3. Dual ETH Quad RS485 Computer Based On CM4
4. Wall Mount Holes On Two Sides, Handy For Mounting
5. Suitable For Raspberry Pi Applications Requiring Multi-Channel RS485 Communication
6. Real-time clock with battery socket and ability to wake Compute Module 4

Specifications:

1. CM4 socket: suitable for all variants of Compute Module 4
2. Networking: Gigabit Ethernet RJ45 connector, 100M Ethernet RJ45 connector
3. USB: USB 2.0 Type A
4. Connector: Isolated RS485 , Power screw terminal
5. Camera:  MIPI CSI-2 port  (15pin 1.0mm FPC connector)
6. Video: HDMI port ,supports 4K 30fps output
7. Storage: Micro-SD card socket for Compute Module 4 Lite (without eMMC) variants
8. Fan Header: allows speed adjustment 5V
9. Indicator: Power indicator , CM4 status indicator
10. Power input: 7-36V
11. Product weight: 280g
12. Dimension: 12 x 10 x 3 mm

Package Include:

1 X CM4-ETH-RS485-BASE-B

1 X Fan

1 X Screwdriver

1 X Screws pack

This is a RoHS compliant I2C Serial LCD Daughter board that can be connected to a standard 16×2 or 20×4 Character Display Module that supports 4-bit mode. All Character Modules sold on our site support 4-bit mode, and nearly all commercially available 16×2 and 20×4 line character modules support it too.

This board has a PCF8574 I2C chip that converts I2C serial data to parallel data for the LCD display. There are many examples on the internet for using this board with Arduino. Do a search for “Arduino LCD PCF8574“. The I2C address is 0x3F by default, but this can be changed via 3 solder jumpers provided on the board. This allows up to 3 LCD displays to be controlled via a single I2C bus (giving each one it’s own address)

Specifications and Features:

1. 5V power supply.
2. Serial I2C control of LCD display using PCF8574.
3. Backlight can be enabled or disabled via a jumper on the board.
4. Contrast control via a potentiometer.
5. Can have 8 modules on a single I2C bus (change address via solder jumpers)address, allowing.
6. Size ：41.6 x 19.2 mm.

Package Includes:

1 x IIC/I2C Serial Interface Adapter Module

FT232RL/CH343G USB TO RS232/485/TTL Interface Converter, Industrial Isolation. Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal. unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, and low power consumption.

Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, lightning proof & ESD protection. Onboard self-recovery fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage proof, and improve shock resistance.

Features:

1. A fully automatic transceiver circuit with no delay ensures the USB port communicates with different interfaces fastly and stably, without interfering with each other
2. Onboard TTL serial 3.3V/5V voltage translator, config the TTL level via switch
3. Aluminum alloy enclosure with sandblasting and anodic oxidation, CNC process opening, solid and durable
4. 3 LEDs for indicating the power and transceiver status
5. High-quality USB-B and RS232 connectors, smoothly plug/pull

Package Includes:

1 x CH343G USB TO RS232/485/TTL Interface Converter, Industrial Isolation

1 x USB Cable
