M5Stack Unit Cam Wi-Fi Camera (OV2640) is a very cost-effective WiFi camera, using ESP32-WROOM-32E control core + 2MegaPixel image sensor (OV2640) solution on the hardware, using the most simplified design, no extra peripherals. The factory software integrates image transmission firmware, provides image data acquisition, image parameter (white balance, exposure, gain, size and other attributes) adjustment interface, users can directly acquire image data through UART or WiFi, and interact with the camera. Support UIFlow graphical programming call, realize zero development, out-of-the-box user experience. The compact design and cost performance are suitable for various wireless camera application scenarios.
Applications
1 x M5Stack Unit Cam Wi-Fi Camera (OV2640)
| Camera |
OV2640 |
|---|---|
| Flash Memory |
4M |
| Firmware default communication method |
UART: 115200bps 8N1 |
| Maximum resolution |
2MegaPixel |
| Unit CAM firmware default picture transfer rate |
12fps |
| OV2640 supports output format |
YUV(422/420)/YCbCr422 ,8-bit compressed data ,RGB565/555 ,8-/10-bit Raw RGB data |
| OV2640 supports the maximum image transfer rate |
UXGA/SXGA: 15fps ,SVGA: 30fps ,CIF: 60fps |
| DFOV |
66.5° |
| Length (mm) |
45 |
| Width (mm) |
20 |
| Height (mm) |
12 |
| Weight (gm) |
5 |
Only logged in customers who have purchased this product may leave a review.
Shipping and Delivery Policy
1. Shipping Process:
2. Shipping Charges:
3. Order Tracking:
4. Delivery Address:
5. Delivery Issues:
6. No Return Policy for Opened/Soldered Products:
7. Refund Policy:
Out of stock
Out of stock
Out of stock
Out of stock
| CMOS size |
1/4inch |
|---|---|
| Aperture (F) |
2.35 |
| Focal Length |
3.15mm |
| Angle of View (diagonal) |
160 degree |
| Distortion |
<14.3% |
| Supports |
CM3/3+/4 ,Jetson Nano ,Jetson Xavier NX |
| Pixels |
8 MP |
| Sensor |
IMX219 |
| Resolution |
3280 × 2464 |
| 4 screw holes |
Used for attachment ,Provides 3.3V power output |
| Product weight |
15g |
| Dimensions |
25mm × 24mm |
Out of stock
Out of stock
| Model |
IMX219-83 |
|---|---|
| Megapixels |
8 MP |
| Sensor |
IMX219 |
| Resolution |
3280 × 2464 (per camera) |
| Lens specifications |
CMOS size: 1/4inch Focal Length: 2.6mm The angle of View: 83/73/50 degree (diagonal/horizontal/vertical) Distortion: <1% Baseline Length: 60mm |
| ICM20948 Accelerometer |
Resolution: 16-bit Measuring Range (configurable): ±2 ,±4 ,±8 ,±16g Operating Current: 68.9uA |
| Gyroscope |
Resolution: 16-bit Measuring Range (configurable): ±250 ,±500 ,±1000 ,±2000°/sec Operating Current: 1.23mA |
| Magnetometer |
Resolution: 16-bit Measuring Range: ±4900μT Operating Current: 90uA |
| Dimennsions |
24mm × 85mm |
Out of stock
| Pixels |
5MP |
|---|---|
| Sensor |
OV5640 |
| Interface |
USB 2.0 |
| Camera Details |
size 1/4 inch Aperture: (F) 2.8 Focal length: (EFL) 3.29 mm Field of view: (FOV) 68° Distortion: < 1% |
| Focusing (B) |
AF Auto-Focus (C): FF Fixed-Focus |
| Image |
Format support MJPG ,YUV422 |
| Resolution |
Static image2592 × 1944 Video recording: 15 FPS 2592 × 1944 30 FPS: 1920 × 1080 30 FPS: 1280 × 720 |
| Operating voltages |
5V ± 5% |
| Camera size |
8.5 × 8.5 mm |
| Module size |
9 × 62 mm         |
