Are you searching for a temperature sensor having high accuracy? Then, the Grove Temperature Sensor v1.2 is perfect for you. It uses a thermistor as a form of resistance value to alter the Vcc. The resistance of a thermistor will increase when the ambient temperature decreases. Its this characteristic that we use to calculate the ambient temperature. Depending on the temperature measured, it supplies an analog signal from 0 to 5 Vcc. The detectable range of this sensor is -40 to 125C and the accuracy is 1.5C.
For all Grove users (especially beginners), Seeed Studio provides guidance PDF documents. Please download and read through Preface Getting Started and Introduction to Grove before using the product. This is a suitable product for not only Grove users but also all electronic enthusiasts. So, why wait? Buy now
1 x Seeed Studio Grove – Air Quality Sensor(BME688) with built-in AI, High-Performance 4-in-1, Gas, Humidity, Pressure and Temperature sensor
Thermistor Zero Power Resistance |
100 K |
---|---|
Resistance Tolerance |
1% |
Nominal B-Constant |
4250 to 4299K |
Operating Temperature Range (C) |
40 to 125 |
Accuracy |
1.5C |
Only logged in customers who have purchased this product may leave a review.
Shipping and Delivery Policy
1. Shipping Process:
2. Shipping Charges:
3. Order Tracking:
4. Delivery Address:
5. Delivery Issues:
6. No Return Policy for Opened/Soldered Products:
7. Refund Policy:
Out of stock
Out of stock
Out of stock
Product Name |
Figaro TGS 2600 Air Quality Sensor |
---|---|
Input Voltage (V) |
5.0±0.2V AC/DC |
Load Resistance |
variable 0.45kΩ min. |
Heater Resistance (Ω) |
approx 83Ω at room temp. (typical) |
Heater current (mA) |
42±4mA |
Heater power consumption (mW) |
210 |
Sensor Resistance (kΩ) |
10kΩ ~ 90kΩ in air |
Sensitivity (change ratio of Rs) |
0.3~0.6 Rs (10ppm of H2)/ Rs air |
Out of stock
Model No. |
TGS2602-B00 |
---|---|
Heater Voltage |
5.0±0.2V DC |
Circuit Voltage |
5.0±0.2V DC |
Heater power consumption |
280mW (typical) |
Heater Current |
56±5mA |
Sensing Principle |
MOS type |
Heater Resistance |
approx 59Ω at room temp. (typical) |
Load Resistance |
variable 0.45kΩ min |
Sensor Resistance |
10kΩ ~ 100kΩ in air |
Standard Package |
TO-5 metal can |
Target Gases |
Air contaminants (VOCs ,ammonia ,H2S ,etc.) |
Test Gas Conditions |
normal air at 20±2˚C ,65±5%RH |
Out of stock
Model No. |
TGS2611-C00 |
---|---|
Sensing Principle |
MOS type |
Standard Package |
TO-5 metal can |
Target Gases |
Methane ,Natural Gas |
Heater Voltage |
5.0±0.2V DC |
Circuit Voltage |
5.0±0.2V DC |
Load Resistance |
variable 0.45kΩ min. |
Heater Resistance |
approx 59Ω at room temp. |
Heater Current |
56±5mA |
Heater power consumption |
280mW±25mW |
Sensor Resistance |
0.68~6.8kΩ in 5000ppm methane |
Test Gas Conditions |
Methane in air at 20±2˚C ,65±5%RH |
Out of stock
Model No. |
TGS3870-F00 |
---|---|
Circuit Voltage |
5.0±0.2V DC pulse |
Load Resistance |
variable (>0.75kΩ) |
Sensing Principle |
MOS type |
Sensor Resistance |
0.3kΩ~5.0kΩ in 3000ppm methane 2kΩ~40kΩ in 200ppm CO |
Standard Package |
Plastic base and metal can |
Target Gases |
Methane and Carbon Monoxide |
Test Gas Conditions |
Target gas in air at 20±2˚C ,65±5%RH |
Out of stock
Model No. |
TGS5042-A00 |
---|---|
Target Gases |
Carbon monoxide |
Typical detection range |
0 ~ 10 ,000ppm |
Output current in CO |
1.2~2.4nA/ppm |
Baseline offset(*1) |
<±10ppm equivalent |
Operating & storage temperature (*2,*3) |
-5ËšC ~ +55ËšC |
Operating humidity |
5 ~ 99%RH (no condensation) |
Response time (T90) |
within 60 seconds |
Standard test conditions |
20±2˚C ,40±10%RH |
