₹8,954.85 (Including tax)
Discount per Bulk Quantity
Quantity | Discount | Price |
---|---|---|
5 - 10 | 5% | ₹8,507.11 (Including tax) |
11 - 20 | 8% | ₹8,238.46 (Including tax) |
21 - 40 | 10% | ₹8,059.37 (Including tax) |
41 - 100 | 12% | ₹7,880.27 (Including tax) |
Out of stock
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Get the Priority Shipping on Prepaid Orders
Prepaid Orders
Get Normal Delivery (Surface) with Cash On Delivery
COD Orders
The LAUNCHXL-RM42 LaunchPad is an inexpensive evaluation platform based on Hercules RM42L432, which is a dual-core ARM Cortex-R4-based MCU with features like 12-bit ADC, HET with programmable timer pins, eQEP, MibSPI, and serial communication interfaces. The LaunchPad comes pre-programmed with the Hercules Safety MCU Demo enabling users to easily learn about the key safety, data acquisition, and control features of the Hercules MCU platform.
                    note: For more technical details, go through the datasheet in the attachments
1 x RM42 Development Board, RM42x, Hercules Launchpad, USB powered, on board XDS100v2 J-TAG emulator
Only logged in customers who have purchased this product may leave a review.
Shipping and Delivery Policy
1. Shipping Process:
2. Shipping Charges:
3. Order Tracking:
4. Delivery Address:
5. Delivery Issues:
6. No Return Policy for Opened/Soldered Products:
7. Refund Policy:
Out of stock
Out of stock
Out of stock
Out of stock
Processor |
Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz H.265 (HEVC) (up to 4Kp60 decode) ,H.264 (up to 1080p60 decode ,1080p30 encode) OpenGL ES 3.0 graphics |
---|---|
Memory |
4GB LPDDR4-3200 SDRAM |
Storage |
Support boot from SD Card( Capacity can be chosen from 32GB~256GB) Support boot from SSD hard disk driver(Capacity can be chosen from 120GB~1TB |
Multimedia |
8-megapixel camera (Optional ) 2 channel 1W stereo speakers 1-channel MEMS microphone Support headphone jack and external microphone 1 standard HDMI 4K high-definition output interface 1 channel Micro HDMI 4K high-definition output interface |
Network and wireless |
1 channel 10/100/1000M Ethernet 2.4G/5.8G dual-band WiFi ,compatible with IEEE 802.11 b/g/n/ac Bluetooth BLE5.0 1 official Raspberry Pi external antenna 4G/LTE version optional (non-SSD hard disk version) |
Interface |
2 channels USB3.0 1 channel way USB2.0 |
Other |
One-click switch turns on/off the system with power & status LED indication RTC built-in with a backup battery |
Power Supply |
USB Type C interface ,5V/3A DC input |
Dimensions (L x W x H) mm |
100 x 100 x 19 |
Weight |
260g |
Software Environment |
Raspbian Desktop version pre-installed |
Out of stock
Model |
ED-CM4NANO10-0108-C |
---|---|
Power supply |
12~18V DC voltage range input 5.5/2.5mm DC Jack or Phoenix terminal connector optional |
Camera and display |
1 x CSI interface ,support Raspberry Pi official 5M & 8M pixel camera module 1 x HDMI port 1 x DSI interface ,support Raspberry Pi official display |
Wired interface |
1 x Support PoE power supply 10/100M/1000 Ethernet (requires official PoE HAT) 2 x USB3.0 (external) 1 x USB3.0 (built-in) 1 x USB2.0 |
Wireless communication |
1 x 2.4G/5.8G WiFi compatible with IEEE 802.11 b/g/n/ac standard 1 x Bluetooth 5.0 BLE WiFi/BLE external antenna and PCB antenna are optional |
Storage |
1 x microSD card holder (used to expand user data storage) Extensible interface: 1 x Raspberry Pi standard 40-pin connector 1 x Raspberry Pi standard 4-pin POE connector |
Operating temperature |
-25~60°C |
Dimension |
103 mm(L) x 62 mm(W) x 21.5mm(H) |
Software Environment |
Raspberry Pi Raspbian OS installed |
Others |
1 x RTC with a backup battery 1 x Red LED power indicator ,1 x Green LED status indication 1 x system reset button 1 x buzzer |
Out of stock
Out of stock
CPU |
Allwinner H3 ,Quad-core Cortex-A7 Up to 1.2GHz |
---|---|
DDR3 RAM |
256MB/512MB |
Connectivity |
10/100M Ethernet |
USB Host |
Type-A x 1 ,2.54 mm pin x 2 |
Debug Serial Port/UART0 |
4Pin ,2.54 mm pitch pin header |
MicroUSB |
OTG ,for power input |
GPIO |
2.54mm pitch 36pin. It includes UART ,SPI ,I2C ,IO etc |
PCB Dimension |
40 x 40 mm |
Power |
DC 5V/2A |
Working temperature |
-20℃ to 70℃ |
OS Support |
 FriendlyCore 16.04(based on UbuntuCore-16.04) FriendlyWrt 19.07.1(32-bit) Armbian DietPi Lakka Kali |
Out of stock
CPU |
big.LITTLE,Dual-Core Cortex-A72(up to 2.0GHz) + Quad-Core Cortex-A53(up to 1.5GHz) |
---|---|
GPU |
Mali-T864 GPU,supports OpenGL ES1.1/2.0/3.0/3.1 ,OpenCL ,DX11 ,and AFBC |
NPU |
4K VP9 and 4K 10bits H265/H264 60fps decoding ,Dual VOP ,etc |
DDR3 RAM |
1GB DDR3/4GB LPDDR4 |
Storage |
No Onboard eMMC |
Network |
One Native Gigabit Ethernet ,and one PCIe Gigabit Ethernet |
PMU Power Management |
RK808-D PMIC ,cooperated with independent DC/DC ,enabling DVFS ,software power-down ,RTC wake-up ,system sleep mode |
USB Host |
Two USB 3.0 Type-A ports |
Debug Serial Port/UART0 |
One Debug UART ,3 Pin 2.54mm header ,3V level ,1500000bps |
MicroSD Slot |
1 |
GPIO |
2×5-pin header: SPI x 1 ,I2C x 1 |
4-pin header |
USB 2.0 |
LED |
1 x power LED and 3 x GPIO Controlled LED (SYS ,LAN ,WAN) |
PCB Dimension |
8 Layer ,66 mm x 66 mm |
Power |
DC 5V/3A ,via USB-C connector or Pin header |
Working temperature |
-20℃ to 70℃ |
