Velodyne Puck Hi-Res Lidar Sensor

11 People watching this product now!

SKU: rz24312992 Category: LiDAR Sensor

Description

Velodyne Puck Hi-Res Lidar Sensor

Velodyne Puck Hi-Res Lidar Sensor is designed for applications requiring greater image resolution. While retaining the Puck’s surround view and best-in-class range, the Puck Hi-Res™ sensor delivers a 20° vertical field-of-view for tighter channel distribution.

Expanding on Velodyne Lidar’s groundbreaking VLP-16 Puck Hi-Res, a 16-channel, real-time 3D lidar sensor that weighs just 830 grams, Puck Hi-Res is used in applications that require greater resolution in the captured 3D image. Puck Hi-Res retains the Pucks’s 360° horizontal field-of-view (FoV) and 100-meter range, but delivers a 20° vertical FoV for a tighter channel distribution – 1.33° between channels instead of 2.00° – to deliver greater details in the 3D image at longer ranges. This will enable the host system to not only detect but also better discern, objects at these greater distances.

Applications: Robotics, Automotive, Industrial, Security, UAV, Mapping

Features:

100 m range with the compact form factor
Higher-resolution option in the Puck family
Proven, Class 1 eye-safe 905 nm technology
Best-in-class accuracy and calibrated intensity
Best-in-class power & temperature range
Sensor-to-sensor interference mitigation feature
Versatile, with attractive volume pricing
Dual Returns

Package Includes:

1 x Velodyne Puck Hi-Res Lidar Sensor

1 x Accessories Set

Additional information

Field of View (Vertical)	± 10°
Field of View (Horizontal)	360°
Returns Type	Dual
No. of Channels	16 channels
Range	100m
Points per second	Up to ~600 , 000
