₹347.40 (Including tax)
Discount per Bulk Quantity
| Quantity | Discount | Price |
|---|---|---|
| 5 - 10 | 5% | ₹330.02 (Including tax) |
| 11 - 20 | 8% | ₹319.61 (Including tax) |
| 21 - 40 | 10% | ₹312.66 (Including tax) |
| 41 - 100 | 12% | ₹305.71 (Including tax) |
Out of stock
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Get the Priority Shipping on Prepaid Orders
Prepaid Orders
Get Normal Delivery (Surface) with Cash On Delivery
COD Orders
MP905 gas sensor is for air quality. It adopts multilayer thick film manufacturing technology. The heater and metal oxide semiconductor material on the ceramic substrate of subminiature Al2O3 are fetched out by electrode down-lead, encapsulated in metal socket and cap. Conductivity of the sensor is affected by the concentration of target gas. The higher the concentration is, the higher conductivity of sensor gets. Users can adopt simple circuit to convert variation of conductivity into output signal corresponding to gas concentration. search and produce air quality monitoring gas sensor for household and office harmful gas detection, automatic exhaust device, air cleaner.
Applications:
It ( MP905 air quality gas sensor) is used in occasions such as household and office for harmful gas detection, automatic exhaust device, air cleaner & etc.
1 x Winsen MP905 Air-Quality Gas Sensor
Only logged in customers who have purchased this product may leave a review.
Shipping and Delivery Policy
1. Shipping Process:
2. Shipping Charges:
3. Order Tracking:
4. Delivery Address:
5. Delivery Issues:
6. No Return Policy for Opened/Soldered Products:
7. Refund Policy:
Out of stock
Out of stock
| Detection Gas |
Hydrogen (H2) |
|---|---|
| Detection range |
0~1000ppm |
| Working Voltage |
3.3~5.5V DC |
| Working Current |
<5mA |
| Output Signal |
I2C ,UART (0~3V) ,analog voltage |
| Working Temperature |
-20~50℃ |
| Working Humidity |
15~90%RH (non-condensing) |
| Storage Temperature |
-20~50℃ |
| Communication Protocol |
I2C ,UART and analog |
| Compatibility |
Arduino ,ESP32 ,Raspberry pi |
| Storage Humidity |
15~90%RH (non-condensing) |
| Lifespan |
>2 years (in the air) |
| Adapter Plate Size |
37 x 32mm |
Out of stock
Out of stock
Out of stock
| Product Name |
Figaro TGS 2600 Air Quality Sensor |
|---|---|
| Input Voltage (V) |
5.0±0.2V AC/DC |
| Load Resistance |
variable 0.45kΩ min. |
| Heater Resistance (Ω) |
approx 83Ω at room temp. (typical) |
| Heater current (mA) |
42±4mA |
| Heater power consumption (mW) |
210 |
| Sensor Resistance (kΩ) |
10kΩ ~ 90kΩ in air |
| Sensitivity (change ratio of Rs) |
0.3~0.6 Rs (10ppm of H2)/ Rs air |
Out of stock
| Model No. |
TGS2611-C00 |
|---|---|
| Sensing Principle |
MOS type |
| Standard Package |
TO-5 metal can |
| Target Gases |
Methane ,Natural Gas |
| Heater Voltage |
5.0±0.2V DC |
| Circuit Voltage |
5.0±0.2V DC |
| Load Resistance |
variable 0.45kΩ min. |
| Heater Resistance |
approx 59Ω at room temp. |
| Heater Current |
56±5mA |
| Heater power consumption |
280mW±25mW |
| Sensor Resistance |
0.68~6.8kΩ in 5000ppm methane |
| Test Gas Conditions |
Methane in air at 20±2˚C ,65±5%RH |
Out of stock
Out of stock
