DALY Li-ion NMC 6S 24V 20A Battery Management System – BMS Protection Board

Click to enlarge

DALY Li-ion NMC 6S 24V 20A Battery Management System – BMS Protection Board

Name: DALY Li-ion NMC 6S 24V 20A Battery Management System - BMS Protection Board - Robozar
Brand: Robozar
SKU: rz24332304
Price: 977.50 INR
Availability: OutOfStock
Rating: 5.00 (2 reviews)

Rated 5.00 out of 5 based on 2 customer ratings

(2 customer reviews)

₹1,153.46 (Including tax)

Discount per Bulk Quantity

Quantity	Discount	Price
5 - 10	5%	₹1,095.79 (Including tax)
11 - 20	8%	₹1,061.18 (Including tax)
21 - 40	10%	₹1,038.11 (Including tax)
41 - 100	12%	₹1,015.04 (Including tax)

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

Fast Shipping
Get the Priority Shipping on Prepaid Orders

Prepaid Orders

Normal Shipping
Get Normal Delivery (Surface) with Cash On Delivery

COD Orders

Compare

Add to wishlist

12 People watching this product now!

SKU: rz24332304 Categories: All Products, BMS, Cell Capacity Meters, Charger Modules, Featured Products, Latest Products, Test & Measurement Tags: [C] Cell Capacity Meter, Battery Accessories, Battery Charger, Battery Protection Board, BMS, In Stock, Lithium Battery, M30

Description

Daly 6S 24V 20A is a Lithium Battery Protection Board (PCM BMS) for balance charging. It uses an A-level protective integrated circuit IC. Its high load capabilities and 20A continuous discharge current performance make it a reliable solution for battery packs. It features a power MOSFET with a high voltage resistance and a low inner resistance. The heat sink will significantly aid cooling.
IC itself has a power balancing function though the circuit is simple and reliable. It features typical voltage detection for each cell. So, that each battery will be prevented from overcharging or over-discharge conditions. This BMS has reliable Over current and short circuit protection function due to which long time short circuit of the load won’t affect the PCB and the battery.
Continuous temperature monitoring through NTC and thermal protection during charging and discharging.
Extremely low power consumption and the current consumption of the whole device is less than 100uA.
This BMS uses a high anti-corrosion, high water resistance, and high impedance ESD conformal coating.

Features:

State of charge calculations.
Cell over-voltage and under-voltage protection.
Intelligent battery balancing (passive).
Fully sealed waterproof technology, with waterproof, dustproof, shockproof, anti-squeezing, and other protective functions.

Package Includes:

1 x Daly 6S 24V 20A Battery Management System

Specifications :

Model	6S 24V 20A
Charge Voltage(V)	24
Charge Current(A)	10
Balance Current(mA)	30±5
Balance Detect Voltage(V)	4.18
Working Current(uA)	100
Overcharge Detect Voltage(V)	4.25±0.05
Overcharge Release Voltage(V)	4.15±0.05
Over Discharge Detect(V)	2.7±0.1
Over Discharge Release(V)	3.0±0.1
Working Temperature Range (°C)	-20 to 70
Cable Size (AWG)	14
Length (mm)	58
Width (mm)	33
Height (mm)	8.2
Weight (gm)	45
Shipment Weight	0.055 kg
