DWIN HMI 3.5 Inch Ips LCD Capacitive Touch Display

5,155.25 (Including tax)

  1. Operating Voltages:5V typical.(MIN:4.5V,MAX:5.5V)
  2. Integrated smart screen
  3. Brightness 300nit
  4. 16.7M colours
  5. FLASH Memory 16Mbytes
  6. RAM Memory:128Kbytes
  7. DMG48320C035_03WTC

Discount per Bulk Quantity

QuantityDiscountPrice
5 - 105%4,897.49 (Including tax)
11 - 208%4,742.82 (Including tax)
21 - 4010%4,639.73 (Including tax)
41 - 10012%4,536.61 (Including tax)

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

  • fast delivery Fast Shipping

    Get the Priority Shipping on Prepaid Orders

Prepaid Orders

  • normal shipping Normal Shipping

    Get Normal Delivery (Surface) with Cash On Delivery

COD Orders

16 People watching this product now!
SKU: rz24318934 Category:
Description

This DWIN 3.5 inch SMART Screen is quite useful and is full features load SMART screen. It is called SMART screen because it comes with UI development Software pre-installed from the manufacturer which gives users great and useful tools to develop their own UI with great features. One can design UI Such as a button, slider, Graph, Text Display, etc on their own.

User can Develop their own UI Using the software provided and pre-installed for it called TA / DGUS II ( DGUS II pre-installed). Also, it is supported with RGB colour and 16.7M colours. It is also equipped with 300 nit brightness which makes it visible in daylight too.

It is compatible with All micro-controller Boards like Arduino, Raspberry and many more… which can be interface with I2C communications.


Features:

  1. Built-in DGUS II intelligent software
  2. Powerful data management
  3. Active Area (AA):49.0mm (W) ×73.4mm (H)
  4. Dimensions:103.3(W) mm× 61.1(H)mm × 12.3(T)mm capacitive touch panel, Built-in Buzzer, WIFI_10 module
  5. Powerful data management
  6. Built-in DGUS II intelligent software

Display:

  1. Size – 3.5″
  2. Display Format -320×480
  3. Brightness -300nit
  4. Active Area – 49.0mm (W) ×73.4mm (H)
  5. Colour – 24-bit colour 8R8G8B
  6. Backlight – LED

Interface:

  • UART4: Optional N81/E81/O81/N82 four-mode, 3.3V TTL/CMOS ( Be used after OS
    configuration )

Package Includes :

1 x 3.5″ Smart Screen

Additional information
Model

DMG48320C035_03WTC

Operating Voltage (VDC)

4.5 ~ 5.5

Interface

I2C

,

UART

Flash Memory

16MB

RAM

128KB

LED Brightness (MCD)

300

Touch Type

Capacitive
