MURATA Ultrasonic Sensor, Receiver, MA40 Series, 9.9 mm Diameter, 40 kHz, -63 dB, -40 °C to 85 °C

1,043.53 (Including tax)

  1. Product: Ultrasonic Sensor, Receiver, MA40 Series, 9.9 mm Diameter
  2. Insulation Resistance :> 100 Mohm
  3. Operating Frequency: 40.0kHz
  4. Capacitance: 2,550pF +/- 20%

Discount per Bulk Quantity

QuantityDiscountPrice
5 - 105%991.35 (Including tax)
11 - 208%960.04 (Including tax)
21 - 4010%939.18 (Including tax)
41 - 10012%918.31 (Including tax)

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

  • fast delivery Fast Shipping

    Get the Priority Shipping on Prepaid Orders

Prepaid Orders

  • normal shipping Normal Shipping

    Get Normal Delivery (Surface) with Cash On Delivery

COD Orders

18 People watching this product now!
SKU: rz2439798 Category:
Description
MA40S4R is an ultrasonic receiver sensor. MA40S4R consists of piezoelectric ceramics, metal plates, resonators, and resin cases. The resonator has a funnel shape to transmit ultrasonic waves which are generated by the vibration of the resonator to the air efficiently(or to concentrate ultrasonic waves from the air on the center of resonance). Sound pressure level(S.P.L.) is the most important characteristic of ultrasonic transducers. For example, in measuring distance application, a high S.P.L. transducer enables to detect the further distance. High S.P.L. and high sensitivity Compact size (10.0mm dia.) Open type structure (used for indoor applications)

Features:

  1. High S.P.L. and high sensitivity
  2. Compact size(10.0mm dia.)
  3.  Open type structure

Package Includes:

1 x Ultrasonic Sensor, Receiver, MA40 Series, 9.9 mm Diameter, 40 kHz,

Additional information
Operating Temperature Range (°C)

-40 ~ +85 degC

Storage Temperature Range

-40 ~ +85 degC

Input Voltage (V)

20Vp-p at 40kHz

,

Square continuous wave Ratings of MA40S4R

S.P.L. (Sound Pressure Level)

120 +/- 3 dB

Insulation Resistance

>100 Mohm

Operating Frequency

40.0kHz

Capacitance

2

,

550pF +/- 20%
