SeeedStudio Grove Differential Amplifier

2,441.25 (Including tax)

  1. Operating Voltage: 5.5
  2. High amplifying precision
  3. General-purpose instrumentation
  4. Gain: 35

Discount per Bulk Quantity

QuantityDiscountPrice
5 - 105%2,319.19 (Including tax)
11 - 208%2,245.94 (Including tax)
21 - 4010%2,197.13 (Including tax)
41 - 10012%2,148.29 (Including tax)

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

  • fast delivery Fast Shipping

    Get the Priority Shipping on Prepaid Orders

Prepaid Orders

  • normal shipping Normal Shipping

    Get Normal Delivery (Surface) with Cash On Delivery

COD Orders

10 People watching this product now!
SKU: rz24318219 Category:
Description

Find setting up an amplifier IC on the breadboard a troublesome and totally no-need-to-repeat job? This Grove module can save you clutter to settle up such an IC by integrating the whole operating circuit. It’s designed for precise differential-input amplification. Input the differential signals of your sensor to this module through the male pins, then your Arduino will get a precisely amplified output from the Grove interface. The gain scale factor is selectable. You can get 35 times or 1085 times amplification via a switch on the board

Getting Started With SeeedStudio Grove Differential Amplifier


Features:

  1. High amplifying precision
  2. Selectable scale factor
  3. Can be conveniently read by Arduino
  4. Strong input protection

Interface Function:

Untitledds

  1. J2: Signal Source Interface
  2. J1: Output Interface, Standard Grove Interface
  3. R1: 62Ω gain resistor
  4. R3: 200Ω gain resistor
  5. U1: INA125 IC, Instrumentation amplifier

Application:

  1. Data acquisition
  2. Battery operated systems
  3. Pressure and temperature bridge amplifiers
  4. General-purpose instrumentation

Package Includes :

1 x SeeedStudio Grove Differential Amplifier

Additional information
Operating Voltage(V)

3.3~5.5

Input Voltage (V)

0.1/(Vcc-0.8)/Gain

Output Voltage(V)

Vcc-0.80

Max Gain

35/1085
