Waveshare 1.54inch 152×152 Yellow/Black/White Three-Color E-Ink Display Module
₹1,499.00
- Operating voltage: 3.3V/5V
- Interface: 3-wire SPI, 4-wire SPI
- Dot pitch: 0.181 × 0.181
- No backlight keeps displaying last content for a long time even when power down
- Ultra-low power consumption, basically power is only required for refreshing
- SPI interface, for connecting with controller boards like Raspberry Pi/Nucleo, etc.
Did you like this product? Add to favorites now and follow the product.
+91-7231900002 Connect on Whatsapp
Description
This is a Waveshare 1.54inch 152×152 Yellow/Black/White Three-Color E-Ink Display Module. The E-Ink display module, 1.54inch, 152×152 resolution, with embedded controller, communicating via SPI interface, supports yellow, black, and white three-color display. Due to the advantages like ultra-low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf labels, industrial instruments, and so on.
Useful link:
To do Hardware and Software setup, please follow this tutorial.
Features:
- No backlight keeps displaying last content for a long time even when power down
- Ultra-low power consumption, basically power is only required for refreshing
- SPI interface, for connecting with controller boards like Raspberry Pi/Nucleo, etc.
- Onboard voltage translator, compatible with 3.3V/5V MCUs
- Comes with development resources and manual (examples for Raspberry Pi/Jetson Nano/STM32)
Package Includes:
1 x Waveshare 1.54inch 152×152 yellow/black/white three-color E-Ink display module
Additional information
Operating Voltage (VDC) | 3.3/5 |
---|---|
Interface | 3-wire SPI, 4-wire SPI |
Display Resolution | 152 × 152 |
Display Color | yellow, black, white |
Full Refresh Time (s) | 27 |
Refresh Power | 26.4mW |
Standby Power (mW) | <0.017 |
Viewing Angle | >170° |
Length (mm) | 50 |
Width (mm) | 33 |
Height (mm) | 8.5 |
Weight (gm) | 13 |
