Waveshare USB Type-C Male To USB-A Female Adapter

SKU: 1486423
Out of stock

129.00

Add to Wishlist
Add to Wishlist
  1. Plug and Play Adapter
  2. Fast Transfer supported
  3. Mini Compact Size
  4. Color: Black
  5. Type: USB-A to USB Type-C







Out of stock

Did you like this product? Add to favorites now and follow the product.

Add to Wishlist
Add to Wishlist

Description

Waveshare USB Type-C Male To USB-A Female Adapter is a fast transfer USB 3.0 supported adapter. It is a must adapter in your sack to connect any USB-A Male device to C type female port.  This multipurpose plug-and-play adapter supports fast data transfer speed and quick connection.


Features and Specifications:

  1. Plug and Play Adapter
  2. Fast Transfer supported
  3. Mini Compact Size
  4. Color: Black
  5. Type: USB-A to USB Type-C

Package Includes:

1 x Waveshare USB Type-C Male To USB-A Female Adapter



Quick Comparison

SettingsWaveshare USB Type-C Male To USB-A Female Adapter remove206429-1-CONN, CIRCULAR, PLUG, 4 WAY, 1 remove87831-1420-CONNECTOR, HEADER, 14POS, 2ROW remove3-640441-4-RECEPTACLE, IDC, 2.54MM, 4WAY, removeT812110A101CEU-SOCKET, IDC, S/RELIEF, 2.54MM, remove90327-0308-CONNECTOR, RCPT,IDC Connector, IDC Receptacle, Female, 1.27 mm, 2 Row, 8 Contacts, Cable Mount remove
NameWaveshare USB Type-C Male To USB-A Female Adapter remove206429-1-CONN, CIRCULAR, PLUG, 4 WAY, 1 remove87831-1420-CONNECTOR, HEADER, 14POS, 2ROW remove3-640441-4-RECEPTACLE, IDC, 2.54MM, 4WAY, removeT812110A101CEU-SOCKET, IDC, S/RELIEF, 2.54MM, remove90327-0308-CONNECTOR, RCPT,IDC Connector, IDC Receptacle, Female, 1.27 mm, 2 Row, 8 Contacts, Cable Mount remove
SKU148642314969751497095149701914972051497103
Rating
Price129.00453.00140.0039.0059.0035.00
Stock
Out of stock
In Stock
In Stock
In Stock
In Stock
In Stock
AvailabilityOut of stockIn StockIn StockIn StockIn StockIn Stock
Add to cart

Read more

Add to cart

Add to cart

Add to cart

Add to cart

Add to cart

Description
  1. Plug and Play Adapter
  2. Fast Transfer supported
  3. Mini Compact Size
  4. Color: Black
  5. Type: USB-A to USB Type-C







  1. Straight Mounting Angle
  2. Plug Accepts Pin Contacts
  3. Black Housing
  4. Threaded Coupling Mating Retention Type
  1. Color: Resin Black
  2. Durability: (mating cycles max) 100
  3. First Mate / Last Break: No
  4. Flammability: 94V-0
  5. Glow-Wire Capable: No
  1. Contact Material: Copper alloy
  2. IDC Connector Type: IDC receptacle
  3. Contact Gender: Female
  4. No. of Contacts: 4 contacts
  1. IDC Connector Type: IDC Receptacle
  2. Contact Gender: Female
  3. Pitch Spacing: 2.54mm
  4. No. of Rows: 2 Row
  1. Confirms high-vibration and shock requirements
  2. White colour
  3. UL94V-0 Flammability rating
  4. 1.2A Current rating per contact
Content

Waveshare USB Type-C Male To USB-A Female Adapter is a fast transfer USB 3.0 supported adapter. It is a must adapter in your sack to connect any USB-A Male device to C type female port.  This multipurpose plug-and-play adapter supports fast data transfer speed and quick connection.


Features and Specifications:

  1. Plug and Play Adapter
  2. Fast Transfer supported
  3. Mini Compact Size
  4. Color: Black
  5. Type: USB-A to USB Type-C

Package Includes:

1 x Waveshare USB Type-C Male To USB-A Female Adapter



The 206429-1 is a reverse-sex Circular Connector with UL94V-0 flame-rated thermoplastic housing and free-hanging mounting.

Applications:

Industrial, Commercial, Power Management


Features & Specifications:

  1. Straight Mounting Angle
  2. Plug Accepts Pin Contacts
  3. Black Housing
  4. Threaded Coupling Mating Retention Type
  5. 5/8-24 UNEF-2A Thread

Package Includes:

1 x 206429-1-CONN, CIRCULAR, PLUG, 4 WAY, 1



Pin Header, Square Pin, Wire-to-Board, 2 mm, 2 Rows, 14 Contacts, Through Hole Straight


Features:

  1. Early entry system crimp terminals
  2. Centre polarization key
  3. Locking ramps
  4. Centre polarization slot
  5. Locking windows
  6. Marking feature
  7. Operating temperature range from -55°C to +105°C
  8. UL94V-0 flammability rating
  9. Maximum current per contact is 2A
  10. Maximum voltage is 125V

Specifications:

  1. Operating temperature range: -55°C to +105°C
  2. Maximum voltage: 125V
  3. Color: Resin Black
  4. Durability: (mating cycles max) 100
  5. First Mate / Last Break: No
  6. Flammability: 94V-0
  7. Glow-Wire Capable: No
  8. Guide to Mating Part: No
  9. Keying to Mating Part: None
  10. Lock to Mating Part: Yes
  11. Material: Metal Phosphor Bronze
  12. Material: Plating Mating Gold
  13. Material: Plating Termination Tin
  14. Material: Resin Nylon
  15. Net Weight: 0.716/g
  16. Number of Rows: 2
  17. Orientation Vertical
  18. PC Tail Length: 2.50mm
  19. PCB Locator: No
  20. PCB Retention: None
  21. PCB Thickness: Recommended 1.60mm
  22. Packaging Type: Tube
  23. Pitch: Mating Interface 2.00mm
  24. Pitch: Termination Interface 2.00mm
  25. Plating min: Mating 0.381μm
  26. Plating min: Termination 1.905μm
  27. Polarized to PCB: No
  28. Shrouded: Yes

Package Includes:

1 x 87831-1420-CONNECTOR, HEADER, 14POS, 2ROW

The 3-640441-4 is a 4-position 1-row Wire-to-Post Closed-end Receptacle with socket-type tin-plated copper alloy contacts and standard nylon housing. The strain relief IDC connector has a nickel-pated underplate, locking lance contact retention, and locking ramp mating retention. It is suitable for use with MTA-100 series headers and MTA-100-series IDC posted connectors.


Features:

  1. 250VAC Operating voltage
  2. 90° Cable exit angle
  3. UL94V-2 Flammability rating

Specifications:

  1. Contact Material: Copper alloy
  2. IDC Connector Type: IDC receptacle
  3. Contact Gender: Female
  4. No. of Contacts: 4 contacts
  5. Contact Plating: Tin plated contacts

Package Includes:

1 x 3-640441-4-RECEPTACLE, IDC, 2.54MM, 4WAY,

The T812110A101CEU is a 10-way IDC Socket with strain relief. This IDC socket has phosphor bronze contact and a glass-reinforced thermoplastic/PBT insulator.

Features:

  1. 2.54mm Pitch
  2. Black Colour
  3. UL94V-0 Flame-rated Glass-reinforce Thermoplastic/PBT Insulator
  4. 1000MR Minimum Insulation Resistance
  5. 250VAC/RMS at 60Hz Voltage

Specifications:

  1. IDC Connector Type: IDC Receptacle
  2. Contact Gender: Female
  3. Pitch Spacing: 2.54mm
  4. No. of Rows: 2 Row
  5. No. of Contacts: 10Contacts
  6. Connector Mounting: Cable Mount
  7. Contact Material: Phosphor Bronze
  8. Contact Plating: Gold Plated Contacts
  9. Product Range: T812 Series

Package Includes:

1 x T812110A101CEU-SOCKET, IDC, S/RELIEF, 2.54MM,

The 90327-0308 is a 8-circuit 2-row Picoflex® PF-50 Receptacle, for 28 to 26AWG wire, with tin-plated phosphor bronze contacts and IDT termination. This 90327 series low profile receptacle is made of polyester, mates with low profile vertical 90325, low profile right angle 90800, 90715, 90814, 90779 vertical, 91714 1.27mm pitch Picoflex® PF-50 header. The Picoflex® connector provides high power and signal in a space-saving, robust and reliable package for a diverse range of wire-to-board applications. Picoflex connector provides high-density solutions when flat-flexible connector is not appropriate. A strong one-piece upper housing provides excellent cable retention and is ideal for small circuit size applications. The high-reliability contact features a 4-point interface with cable and two points of contact between the header and receptacle.


Features & Specifications:

  1. Highly reliable, power and signal
  2. Picoflex connector mates with 1.27mm cable – A worldwide industry standard
  3. Excellent polarization to both PCB and between female connector and header
  4. Confirms high-vibration and shock requirements
  5. White colour
  6. UL94V-0 Flammability rating
  7. 1.2A Current rating per contact
  8. 250V Voltage rating
  9. -40 to 105°C Temperature range

Package Includes:

1 x 90327-0308-CONNECTOR, RCPT, 8POS, 2ROW, 1

Weight
