5-200V SSR-25DD Solid State Relay

SKU: rz24317345
In Stock

374.00

  1. Rated Load Current (mA):100A
  2. Dielectric Strength: Over 2.5kVA / 1 min
  3. Trigger Voltage (VDC):3-32VDC
  4. Switching Voltage (VDC):5-200
  5. Operating Temperature Range (C):-20 to 85
In Stock
This item is low in stock.

Item(s) left: 6

Add to Wishlist
Add to Wishlist

Did you like this product? Add to favorites now and follow the product.

Add to Wishlist
Add to Wishlist
Have a Question? Ask a Specialist

+91-7231900002 Connect on Whatsapp

Low Prices

Price match guarantee

Guaranteed Fitment.

Always the correct part

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Description

This is DC To DC SSR-25DD Solid State Relay Module 3-32VDC/5-200VDC 10A. A solid-state relay (SSR) is an electronic switch, which, unlike an electromechanical relay, contains no moving parts. The types of SSR are photo-coupled SSR, transformer-coupled SSR, and hybrid SSR. A photo-coupled SSR is controlled by a low voltage signal which is isolated optically from the load.

The control signal in a photo-coupled SSR typically energizes an LED which activates a photo-sensitive diode. The diode turns on a back-to-back thyristor, silicon-controlled rectifier, or MOSFET transistor to switch the load.

This particular SSR can switch current loads of up to 10A with a 5-200VDC input and a zero cross trigger control method. Each one of these relays is equipped with four screw terminals (for use with ring or fork connectors) and a plastic cover that slides over the top of the relay to protect the terminals.


Features:

  1. Long service life and high reliability
  2. Reduced electromagnetic interference
  3. Highly reliable, compact size designed to offer users maximum simplicity.

Specifications:

  1. Rated Load Current (mA):100A
  2. Dielectric Strength: Over 2.5kVA / 1 min
  3. Trigger Voltage (VDC):3-32VDC
  4. Switching Voltage (VDC):5-200
  5. Operating Temperature Range (C):-20 to 85
  6. Material: ABS
  7. Length (mm):45.5
  8. Width (mm):62.5
  9. Height (mm):24
  10. Weight (gm):93

Package Includes:

1 x 5-200V SSR-25DD Solid State Relay
