89110-0101-SOCKET, IDC, 2.54MM, 10WAY

SKU: rz2434976
In Stock

169.00

  1. IDC Connector Type: IDC Receptacle
  2. Contact Gender: Female
  3. Pitch Spacing: 2.54mm
  4. No. of Rows: 2 Row
  5. No. of Contacts: 10Contacts
In Stock
This item is low in stock.

Item(s) left: 3

Add to Wishlist
Add to Wishlist

Did you like this product? Add to favorites now and follow the product.

Add to Wishlist
Add to Wishlist
Have a Question? Ask a Specialist

+91-7231900002 Connect on Whatsapp

Low Prices

Price match guarantee

Guaranteed Fitment.

Always the correct part

In-House Experts.

We know our products

Easy Returns.

Quick & Hassle Free

Description

The 89110-0101 is a 10-way 0.100 x 0.100-inch IDC Ribbon Cable Socket for 0.050-inch pitch cable, with gold-plated phosphor bronze contacts and IDC/IDT termination. This 891 series socket is glass-filled polyester (PBT) insulated, preassembled, packaging on swords for easy loading of manual and semi-automatic assembly equipment. Double-recessed cover for cable terminating from either side virtually eliminates the need for single-recessed cover connectors, military polarization with center bump and no strain relief.


Features:

  1. Grey color
  2. Bumps are designed to prevent premature latch locking during shipment
  3. UL94V-0 Flammability rating
  4. >1 x 10⁹R at 500VDC Insulation resistance
  5. -55 to 105°C Temperature rating

Specifications:

  1. IDC Connector Type: IDC Receptacle
  2. Contact Gender: Female
  3. Pitch Spacing: 2.54mm
  4. No. of Rows: 2 Row
  5. No. of Contacts: 10Contacts
  6. Connector Mounting: Cable Mount
  7. Contact Material: Phosphor Bronze
  8. Contact Plating: Gold Plated Contacts
  9. Product Range: 891 Series

Package Includes:

1 x 89110-0101-SOCKET, IDC, 2.54MM, 10WAY
