₹1,491.35 (Including tax)
Discount per Bulk Quantity
| Quantity | Discount | Price |
|---|---|---|
| 5 - 10 | 5% | ₹1,416.78 (Including tax) |
| 11 - 20 | 8% | ₹1,372.04 (Including tax) |
| 21 - 40 | 10% | ₹1,342.21 (Including tax) |
| 41 - 100 | 12% | ₹1,312.39 (Including tax) |
Out of stock
No worries! Enter your email, and we'll let you know as soon as it's back in stock.
Get the Priority Shipping on Prepaid Orders
Prepaid Orders
Get Normal Delivery (Surface) with Cash On Delivery
COD Orders
AHS3000 is a constant potential electrolytic sensor used to measure the concentration of hydrogen sulfide gas. It is small, high sensitivity, and fast response. It can be easily integrated into portable instruments, and can also replace the same type of hydrogen sulfide electrochemical sensor through pins. Deliver high-quality products to customers stably and in batches.
Application
AHS3000 has a wide range of application scenarios, suitable for hydrogen sulfide detection in industrial sites and environmental protection fields, portable hydrogen sulfide detection instruments, fixed-point hydrogen sulfide detectors, etc.
1 x Hydrogen sulfide sensor AHS3000
| Operating Temperature Range (°C) |
-40~+55℃ |
|---|---|
| Working Humidity Range |
15~90%RH(Non-Condensing) |
| Measure Range |
0~100ppm |
| Response Time ( μS) |
≤30000 |
Only logged in customers who have purchased this product may leave a review.
Shipping and Delivery Policy
1. Shipping Process:
2. Shipping Charges:
3. Order Tracking:
4. Delivery Address:
5. Delivery Issues:
6. No Return Policy for Opened/Soldered Products:
7. Refund Policy:
Out of stock
Out of stock
| Detection Gas |
Hydrogen (H2) |
|---|---|
| Detection range |
0~1000ppm |
| Working Voltage |
3.3~5.5V DC |
| Working Current |
<5mA |
| Output Signal |
I2C ,UART (0~3V) ,analog voltage |
| Working Temperature |
-20~50℃ |
| Working Humidity |
15~90%RH (non-condensing) |
| Storage Temperature |
-20~50℃ |
| Communication Protocol |
I2C ,UART and analog |
| Compatibility |
Arduino ,ESP32 ,Raspberry pi |
| Storage Humidity |
15~90%RH (non-condensing) |
| Lifespan |
>2 years (in the air) |
| Adapter Plate Size |
37 x 32mm |
Out of stock
Out of stock
| Heater voltage |
5.0±0.2V DC |
|---|---|
| Circuit Voltage |
5.0±0.2V DC |
| Heater Current |
56±5mA |
| Minimum impedance between Pin#2,3 and GND |
2.5MΩ |
| Operating conditions |
0Ëš~40ËšC ,30~95%RH |
| Temperature differential between inside and outside detector casing |
≤10˚C max. (see NOTE 1) |
| Test gas conditions |
1250±100ppm iso-butane in air at 20˚±2˚C ,65±5%RH |
| Circuit conditions |
VH=5.0±0.05V DC VC=5.0±0.05V DC |
Out of stock
| Product Name |
Figaro TGS 2600 Air Quality Sensor |
|---|---|
| Input Voltage (V) |
5.0±0.2V AC/DC |
| Load Resistance |
variable 0.45kΩ min. |
| Heater Resistance (Ω) |
approx 83Ω at room temp. (typical) |
| Heater current (mA) |
42±4mA |
| Heater power consumption (mW) |
210 |
| Sensor Resistance (kΩ) |
10kΩ ~ 90kΩ in air |
| Sensitivity (change ratio of Rs) |
0.3~0.6 Rs (10ppm of H2)/ Rs air |
Out of stock
| Model No. |
TGS2610-C00 |
|---|---|
| Heater Current |
56±5mA |
| Heater Resistance |
approx 59Ω at room temp. |
| Heater Voltage |
5.0±0.2V DC |
| Load Resistance |
variable 0.45kΩ min |
| Sensing Principle |
MOS type |
| Circuit Voltage |
5.0±0.2V DC |
| Sensor Resistance |
1.0~10.0kΩ in 1800ppm iso-butane |
| Standard Package |
TO-5 metal can |
| Target Gases |
Butane ,LP gas |
| Test Gas Conditions |
iso-butane in air at 20±2˚C ,65±5%RH |
| Heater power consumption |
280mW VH = 5.0V DC |
Out of stock
| Model number |
TGS5141-P00 |
|---|---|
| Output current in CO |
1.2~3.2nA/ppm |
| Target Gases |
Carbon monoxide |
| Typical detection range |
0 ~ 5 ,000ppm |
| Baseline offset(*1) |
<±10ppm equivalent |
| Operating temperature |
10ËšC ~ +50ËšC (continuous) -20ËšC ~ +60ËšC (intermittent) |
| Operating humidity |
10 ~ 95%RH (no condensation) |
| Response time (T90) |
within 60 seconds |
| Storage conditions |
-10ËšC ~ +50ËšC (continuous) -20ËšC ~ +60ËšC (intermittent |
| Standard test conditions |
20±2˚C ,40±10%RH |
| Weight |
approx. 2.5g |
Out of stock
