Waveshare 1.47inch LCD Display Module, Rounded Corners, 172×320 Resolution, SPI Interface

(5.00)3 Reviews
Available on backorder

1,309.85 (Including tax)

  1. Model: Waveshare 1.47 inch LCD Display Module
  2. Operating Voltage: 3.3V/5V
  3. Resolution: 172 × 320 pixels
  4. Communication Interface: 4-wire SPI
  5. Display size: 17.39 × 32.35mm
  6. Display Panel: IPS

Discount per Bulk Quantity

QuantityDiscountPrice
5 - 105%1,244.36 (Including tax)
11 - 2010%1,178.87 (Including tax)
21 - 4015%1,113.37 (Including tax)
41 - 10020%1,047.88 (Including tax)
  • Estimated delivery time 2-4 days
  • (Subject to stock Availability)
SKU: rz24310841

Product details

1.47 inch LCD Display Module, Rounded Corners, 172×320 Resolution, SPI Interface. The built-in controller used in this LCD is ST7789V3, which is an LCD controller with 240 x RGB x 320 pixels, while the pixels of this LCD itself are 172(H)RGB x 320(V). There are two types of horizontal and vertical screens, so the internal RAM of the LCD is not fully used.
The LCD supports 12-bit, 16-bit and 18-bit input color formats per pixel, namely RGB444, RGB565, RGB666 three color formats, this demo uses RGB565 color format, which is also a commonly used RGB format
The LCD uses a four-wire SPI communication interface, which can greatly save the GPIO port, and the communication speed will be faster


Useful link:

To do the Hardware setup, please follow this tutorial.

To do the Software setup, please follow this tutorial.


Features:

  1. 172×320 resolution, 262K RGB colors, clear and colorful displaying effect
  2. SPI interface, minimizes required IO pins, supports controller boards like Raspberry Pi/Arduino/STM32
  3. Comes with development resources (examples for Raspberry Pi/Arduino/STM32)

Package include:

1 X 1.47inch LCD Module

1 X PH2.0 8PIN cable

Additional information

Operating Voltage

3.3V/5V

Resolution

172 × 320 pixels

Communication Interface

4-wire SPI

Display size

17.39 × 32.35mm

Display Panel

IPS

Pixel Pitch

0.0337 × 0.1011mm

Driver

ST7789V3
