Waveshare CH343G USB TO RS232/485/TTL Interface Converter Industrial Isolation

₹3,024.75 (Including tax)

Brand: Waveshare
Product: CH343G USB TO RS232/485/TTL Interface Converter
Operating voltage: 5V
Connector: USB-B
Protection: 200mA self-recovery fuse, isolated output
Connector DB9 male

Discount per Bulk Quantity

Quantity	Discount	Price
5 - 10	5%	₹2,873.52 (Including tax)
11 - 20	8%	₹2,782.78 (Including tax)
21 - 40	10%	₹2,722.28 (Including tax)
41 - 100	12%	₹2,661.79 (Including tax)

Out of stock

This product is currently sold out.

No worries! Enter your email, and we'll let you know as soon as it's back in stock.

Fast Shipping
Get the Priority Shipping on Prepaid Orders

Prepaid Orders

Normal Shipping
Get Normal Delivery (Surface) with Cash On Delivery

COD Orders

Compare

Add to wishlist

19 People watching this product now!

SKU: rz24310500 Category: Interface Module

Description

FT232RL/CH343G USB TO RS232/485/TTL Interface Converter, Industrial Isolation. Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal. unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, and low power consumption.

Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, lightning proof & ESD protection. Onboard self-recovery fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage proof, and improve shock resistance.

Features:

A fully automatic transceiver circuit with no delay ensures the USB port communicates with different interfaces fastly and stably, without interfering with each other
Onboard TTL serial 3.3V/5V voltage translator, config the TTL level via switch
Aluminum alloy enclosure with sandblasting and anodic oxidation, CNC process opening, solid and durable
3 LEDs for indicating the power and transceiver status
High-quality USB-B and RS232 connectors, smoothly plug/pull

Package Includes:

1 x CH343G USB TO RS232/485/TTL Interface Converter, Industrial Isolation

1 x USB Cable

Additional information

Operating voltage	3.3V / 5V
Connector	DB9 male
CH343G	up to 2 Mbps (not full band)
Baud rate FT232RL	300bps ~ 2 Mbps
Baud rate	FT232RL: 300bps ~ 921600 bps
Connector Screw	terminal
Direction Control	Hardware automatically discriminates and controls the direction of data transmission
Protection	600W lightningproof and surge-suppress , 15KV ESD protection (reserved 120R balancing resistor solder pads
Transmission mode	Point-to-multipoints (up to 32 nodes , it is recommended to use repeaters for 16 nodes or more)
Pins	TXD , RXD , GND , 5V
