The Multibus Converter is an industrial grade isolated converter that supports USB / RS232 / TTL to RS232 / 485 / TTL, with built-in power supply isolation, digital isolation, and protection circuits like TVS diode. It is easy to use and suitable for industrial control equipments and/or applications with high communication requirement.

NOTE: only one pair of devices will be matched for a complete communication between the Group A and Group B terminals at the same time

Features:

1. Adopts original FT232RL for USB communication, fast communicating, stable and reliable, better compatibility
2. Onboard over-voltage, over-current protection circuits (there’s no protection between the two power supplies of the host terminal)
3. Onboard unibody power supply isolation, providing stable isolated voltage, no extra power supply required for the isolated terminal
4. Onboard unibody digital isolation, for isolating the signal, reliable and jamproof, low power consumption
5. Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit, lightningproof & anti-electrostatic
6. Onboard resettable fuse and protection diodes, ensures the current/voltage stable outputs, provides over-current/over-voltage proof, improves shock resistance
7. Onboard TTL serial port 3.3V and 5V voltage level switch, allows the user to select TTL level of the Group B terminal
8. Aluminum alloy enclosure with oxidation dull-polish surface, solid and durable

Packages Includes:

1 x Waveshare Industrial Isolated Multi-Bus Converter, USB / RS232 / RS485 / TTL Communication

USB TO RS232/485/422/TTL, an industrial-grade isolated converter, adopts the original FT232RNL, built-in protection circuits including power isolation, ADI magnetical isolation and TVS, and with aluminum alloy shell design. USB TO RS232/485/422/TTL is easy to operate and features an automatic transmission and reception conversion with zero delays. Also, it has the characteristics of fast communication speed, stability, reliability, safety, etc., and can be applied to various industrial control device or applications with high communication requirements.

Features:

1. Adopt the original FT232RNL chip, fast communicating, is stable, and reliable, better compatibility
2. Supports multiple communication interface conversion: USB to RS232, USB to RS485, USB to RS422, USB to TTL
3. Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal
4. Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption
5. Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, lightning proof & ESD protection
6. Onboard self-recovery fuse and protection diodes, ensures the current/voltage stable outputs, provide over-current/over-voltage proof, improve shock resistance
7. A fully automatic transceiver circuit with no delay ensures the USB port communicates with different interfaces fastly and stably, without interfering with each other
8. Onboard TTL serial 3.3V/5V voltage translator, config the TTL level via switch
9. 3 LEDs for indicating the power and transceiver status
10. High-quality USB-B and RS232 connectors, smoothly plug/pull
11. Industrial grade metal case supports wall-mount and rail-mount installations, solid and beautiful, easy to install

Specifications:

1. Operating voltage: 5V (USB)
2. Protection: 200mA self-recovery fuse, isolated output (USB)
3. Connector: DB9 male (RS232)
4. Protection: TVS diode, surge protection & ESD protection (RS232)
5. Transmission mode:  Point-to-point (RS232)
6. Baud rate: 300bps ~ 3Mbps (RS232)
7. Connector: Screw terminal (RS485/422)
8. Direction control: Hardware automatic control (RS485/422)
9. Protection: 600W lightning proof and surge-suppress, 15KV ESD protection (reserved two 120R balancing resistors, enabled/disabled via jumper) (RS485/422)
10. Baud rate: 300bps ~ 3Mbps (RS485/422)

Package Includes:

1 x Waveshare FT232RNL USB TO RS232/485/422/TTL Interface Converter, Industrial Isolation

The ENC28J60 Ethernet Module is a board which contains an Ethernet port and converts Ethernet input into SPI. The board is based on Microchips ENC28J60 integrated circuit and it can be used to provide internet connectivity to micro-controller systems like Arduino boards over Ethernet. Since the board is small in size and it supports SPI, it is applicable to a variety of projects.

Utilizes the new SSOP 12 package Microchip ENC28J60 Stand-Alone Ethernet Controller IC featuring a host of features to handle most of network protocol requirements. The board connects directly to most micro-controllers with a standard SPI interface with a transfer speed of up to 25 MHz . The ENC28J60 Ethernet Module is an industry standard Serial Peripheral Interface (SPI). It is designed to serve as an Ethernet network interface for any controller equipped with SPI. This module includes all you need to change your Arduino into an ethernet device for your network. These days many makers prefer WiFi type network communication. Ethernet still has lots of application and still stays a fast and secure way to connect to network devices.

Features :

1. Fully Compatible with 10/100/1000Base-T Networks
2. Integrated MAC and 10Base-T PHY
3. Supports One 10Base-T Port with Automatic Polarity Detection and Correction
4. Supports Full and Half-Duplex modes
5. Automatic Programmable Retransmit on Collision
6. Programmable Padding and CRC Generation
7. Automatic Rejection of Erroneous Packets
8. SPI Interface with Clock Speeds Up to 20 MHz

Specifications:

1. Driver IC: ENC28J60-I/SO
2. Input Supply Voltage: 3.3V
3. Crystal Oscillator: 25 MHz
4. Ethernet Port: Han Run HR911105A
5. SPI Interface with Clock Speeds: 20MHz

Package include:

1 X ENC28J60 Ethernet Module

The RS232 TO RS485 (B) can be widely used for point-to-point, point-to-multipoint, long distance cascaded communication network between two hosts, or between host and MCU/Peripheral. It also can be used in the application scenarios that require RS232 to RS485 conversion such as Industrial Automation and IoT

RS232 TO RS485 (B) is an industrial-grade rail-type active optoisolated RS232 to RS485 converter.

Applications:

1. Industrial Automation
2. Access control
3. Self services banking
4. Parking sevices
5. highway toll stations
6. Attendance system

Features:

Industrial Grade USB HUB, Extending 4x USB 3.2 Ports, Switchable Dual Hosts, Multi Protections

Features:

1. 4x extended USB ports, switchable two inputs, sharing USB devices for two hosts
2. Industrial grade HUB chip, adopting MTT technology, allows stable and smooth 4x concurrent USB connections
3. ESD protection for each USB port, preventing electric surge damage and data loss
4. Over-voltage protection, effectively preventing other high-voltage power input from damaging the connected devices
5. Multiple protection circuits: over-voltage, over-current, short circuit, over-temperature, reverse current, under voltage lock-out, 8KV ESD protection, filtering protection, etc.
6. Industrial grade metal case, rugged & durable, with mounting holes for easy installation

Specifications:

1. Standard: High-Speed USB 3.2 Gen 1
2. Data Rate: Up To 5gbps
3. USB Output: 5v@imax:1.2a, Usb-a Connector
4. USB Hub Input:  5v, Switchable Dual Usb-a Connectors (Standalone Power Supply, No Crossed Power)
5. External Power: Dc Power Supply Terminal 7~36v
6. (Additional Power Supply Is Required For This Hub When Connecting To High Power Devices)
7. Operating Environment: -40℃ ~ 85℃
8. OS Support: Mac OS (8.6 Or Above), Linux(2.4.20 Or Above), Windows 11 / 10 / 8.1 / 8 / 7 / XP

Package Includes:

1 x Waveshare Industrial grade USB HUB Extending 4x USB 3.2 Ports

M.2 To PCIe 4-Ch Expander, Using With PCIe X1 To PCIe X16 Expander

Features:

• Neat Interface Layout Can Effectively Reduce Interface Interference And Ensure Stable Data Transmission
• Expand To 4-Ch PCIe Port Suitable For Application Scenarios That Require Multiple PCIe Ports At The Same Time

Specifications:

1. Model: M2-PCIe-switch-4p
2. Transfer Interface: PCIe X1 Female Port × 4, M.2 Mkey Male Port × 1
3. Operating System: Windows / Linux
4. Dimensions: 80.0 × 22.0mm

1. Model PCIe-x1-to–x16-cable
2. Transfer Interface Pcie X1 Female Port × 1, Pcie X16 Port × 1
3. Power Supply
4. Interface 6pin Header × 2
5. 4pin Header × 1
6. Sata 15pin Header × 1
7. Dimensions 119.80 × 44.83mm

Package Includes:

1 x Waveshare M.2 to PCIe 4-Ch Expander, Using With PCIe X1 to PCIe X16 Expander
