Dual Axis XY Joystick Module

SKU: RZ24344433 Category: Sensors

₹ 62.10

Out of Stock

Buy Dual Axis XY Joystick Module online, Order today to get instant delivery in all over india.

Bulk Discount Pricing

Quantity	Discount	Price / Unit
5 – 10	2%	₹ 60.86
11 – 30	3%	₹ 60.24
31 – 50	4%	₹ 59.62
51 – 100	5%	₹ 59.00

Out of Stock

You're on the list! We'll email you when this product is back in stock.

Enter your email to be notified when this product is available again.

Why Buy From Us

Fast Shipping

Quick dispatch on all orders

Secure Payment

100% safe transactions

GST Invoice

Available on all orders

Easy Returns

7-day return policy

Expert Support

Always here to help

Product Details

Category Sensors

Subcategory Sensors (General)

SKU RZ24344433

The dual Axis XY Joystick module uses two potentiometers (one for each direction) to detect the directional movement. Both the potentiometers are of value 10K and can move in any direction independently. There is a push-button also in the module which can be used by pressing down the joystick.

Dual Axis Joystick module has 5 pins i.e, GND, Vcc, VRx, VRy and SW. GND pin is connected to the ground of the circuit whereas Vcc is connected to the power supply. VRx and VRy pins are used to retrieve analog signal which contains position coordinates of X-axis and Y-axis respectively. SW is connected to the push button. This Joystick Module uses pin interface leads of 2.54mm. The operating voltage for the module is 5V. The main application of the Two-Axis Joystick module is controlling robots, pan control for the camera, game controllers, etc.
