SONOFF NSPanel EU Smart Scene Wall Switch Intelligent Color LCD Touch Smart work with Alexa, Google Home

Do you need one device to centrally control multiple electrical devices in your home, lights, heaters, coolers, curtains, doors and windows? NSPanel can control all of these devices, offering a built-in HMI panel for home automation that’s super convenient, all you need to do is tap.

The NSPanel Smart Scene wall switch is equipped with a powerful built-in thermostat and environmental sensors. You can set different indoor temperatures for different time periods, and NSPanel will automatically trigger heating or cooling equipment based on your setting conditions to keep the room at a comfortable temperature. In addition, NSPanel has a scenario-based control function, you can set different modes for wake up, work, entertainment and sleep, and can change the mode at any time.

Such a powerful panel, how to control it? There are three ways to control SONOFF NSPanel Smart Scene wall switch: use the dual channel switches or touch screen nearby, use the APP to control when you are at a long distance, voice control makes your hand free.

Sonoff NSPanel is compatible with various devices from Sonoff, such as LED bulbs, LED Filament bulbs, LED light strips, S26 / S31, TX, MINIR2, POWR3 plugs!

Features:

1. All in One Control Center: NSPanel can help you operate specific scene modes in different scenes with just one click. In addition to scenario-based control, it is compatible with almost all sonoff devices and the central control function of the control group.
2. Integrated HMI Panel: SONOFF NSPanel centrally integrates HMI control, intelligent temperature control and smart wall switch, turning your home into a convenient and smart place.
3. Home Automation Thermostat: With a powerful built-in thermostat, you can set different indoor temperatures for different time periods, and NSPanel will automatically trigger heating or cooling equipment based on your setting conditions to keep the room at a comfortable temperature.
4. Multiple ways to control: You can use dual channel switches, touch screen and eWeLink app to control SONOFF NSPanel; Besides, SONOFF NSPanel supports Alexa, Alice, Google Assistant and even Siri shortcuts, you can control your home devices with a simple voice command.
5. Know the time and weather: With built-in sensors and WiFi connection, the NSPanel smart wall switch can real-time update the weather, indoor temperature, outdoor temperature, time and date.

Specifications:

1. Input: 100-240V ~ 50 / 60Hz 4A max
2. Output: 100-240V ~ 50 / 60Hz 2A / Group 4A / Total
3. LED load: 150W / 110V / Group, 300W / 110V / Total, 300W / 220V / Group, 600W / 220V / Total
4. Wifi: IEEE 802.11 b / g / n 2.4 GHz
5. Bluetooth standard: 4.2 BLE
6. TFT screen size: 3.5 “(capacitive touch screen)
7. Screen resolution: 480 x 320px
8. APP operating systems: Android and iOS
9. Shell Materials: PC V0 + CRS + Tempered Glass
10. Dimension: 86x86x41.7 mm
11. Certifications: NSPanel-EU: CE / CQC / SRRC / RoHS

Packages Includes:

1 x SONOFF NSPanel EU Smart Scene Wall Switch Intelligent Color LCD Touch Smart work with Alexa, Google Home
