40A 2-6S ESC

An opto ESC isolates the high-power side (battery and motor) from the signal side (connection to the receiver) by internally transmitting the receiver throttle signal from the input side to the output side of the ESC through an opto-coupler.

ReadytoSky 40A 2-6S ESC is specifically made for quadcopters and multi-rotors. Which provides faster and better motor speed control giving better flight performance compared to other available ESCs.

ReadytoSky 40A 2-6 ESC comes with a multi-integrated special program, fast throttle response, surpasses all kinds of open-source software. Firmware was optimized specifically integrated circuitously for the disc motor, and it has very good compatibility and this ESC is compatible with 2-6s Lipo Battery.

Due to ultra-low resistance MOSFET, it has a strong flow capacity. With MOSFET special driver integrated circuit, its performance and stability far surpass the driving circuit with discrete components built.

If you are wandering to build a drone and don’t know what will be the best ESC for you then worry no more, we have got your back. At Robu, we have everything for you to get started with your drone project.

Features:

1. Using Multi integrated circuit opted special program, fast throttle response, surpasses all kinds of open source software
2. Firmware was optimized specific integrated circuit ally for disc motor, and it has a very good compatibility
3. Highly intelligent, strong adaptive capacity, reserve the timing setting item (height/middle timing), easy to use
4. Throttle signal line is twisted wire to reduce crosstalk within the transmission signal generated by the copper, so that more stable flight
5. Supports refresh rates up to 621Hz throttle signal, compatible with various flight controllers. (Note: the throttle signal over 500Hz are all non-standard throttle signal)
6. Using MOSFET special driver integrated circuit, its performance and stability far surpass the driving circuit with discrete components built
7. Ultra-low resistance MOSFET, strong flow capacity

Specifications:

1. Brand: Ready to sky
2. Model:
3. Current: 40A
4. Burst Current(10sec):
5. product: ESC (Electronic Speed Controller )
6. BEC: None
8. :
9. : Timing(high/middle)
10. Usage: RC Multi integrated circuit opted
11. Size: 68x25x8.7mm
12. Weight: 26g

Packages Includes:

1 x ReadytoSky 2-6S 40A OPTO ESC
