Coaxial Pure Copper 3+1 CCTV White Cable 90 Meter

It's a Coaxial Pure Copper 3+1 CCTV White Cable 90 Meter. The Coaxial Pure Copper 3+1 CCTV Cable in White, spanning a length of 90 meters, is an exceptional choice for ensuring top-notch video surveillance in both residential and commercial settings. Crafted from high-quality pure copper, this cable guarantees optimal signal transmission, reducing signal loss and ensuring that your CCTV system delivers clear and uninterrupted video footage. The 3+1 configuration includes three coaxial cables for video transmission and one additional cable for power, simplifying the installation process. The cable's white color not only complements most environments but also offers a clean and discreet appearance. With durability and reliability at its core, this CCTV cable is an indispensable component for maintaining security and peace of mind.

Features

• Core Outer Diameter - 1.35±0.10mm
• Conductor Type - Solid Annealed Bare Copper Conductor
• Colour Code - Red, Yellow & Grey
• No/Size of Wire Video Core- 01/0.60± 0.015mm
• Video Core Insulation- HDPE
• No of Video Core- One
• Colour Video Code- Natural
• Shielded- Al-Mylar
• Braiding- CCA braiding (48 wire/0.12 ± 0.01mm)
• Video Core Jacketng- HDPE
• Colour of Jacket- Black
• Video Core OD- 2.50 ±0.20mm
• Material PVC- PVC
• Colour of Jacketng- White
• Thickness of Outer Jacket- 0.65 mm (Nom.)
• Outer Dia.- 5.70 ± 0.30mm
• Sequental Marking-Every Meter
• Standard Length- 90 Meter
