Orange Esp8266 D1 Mini Pro Wifi Development Board Nodeu Ws2812 Rgb Dht11 Dht22 Am2302 Relay Ds18b20 Bmp180 Motor For Wemos Diy Kit

With a wide range of items offered by the brand, Orange has attracted a lot of attention since our company’s debut. Orange Kit is an insertion of a new product line from our vast expertise knowledge base from past years. Here in this kit series, we are presenting a wide range of the most popular combo products.  At the Orange brand, we’ve gained the confidence of our consumers and got excellent comments for our Battery, Proximity sensor, Motor, BMS, and other products. When it comes to our own brands, Robu Labs tests them all before they are launched.

No matter if you’re a newbie or have some expertise with the product in this kit, you may learn more about it with our Orange Wemos Diy Kit!

In this kit, you will get a variety of electronic modules that can be used to construct or enhance your knowledge of many types of electronic components. Out of the box, the kit has products ESP8266 D1 mini, WeMos D1 mini DHT11 Sensor, etc.

Features:

1. A great way for beginners to get started with Pure Electronics
2. 10 different Wemos modules in a kit
3. All modules are packed in protective plastic bags

Specifications:

Esp8266 D1 mini pro:

1. Chipset:ESP-8266EX
2. Recommended Power Supply:5V 1A
3. Maximum Voltage:24V
4. I/O pins:11

WS28212B RGB Shield:

1. Support the OTA online
2. Supporting the D1 MINI
3. 1 x ADC pin ( 0 – 3.3V )
4. Compatible with Arduino, using Arduino IDE for programming

DS18B20 Shield:

1. Temperature range:-55 to 125 °C
2. Accuracy:±0.5°C
3. Acquisition Accuracy:9 bit to 12 bit

5v relay Module:

1. Power Supply:5V
2. KF301 terminal Control

DHT22 Shield:

1. Operating Voltage:3.3~5 V
2. Temperature:-40 to 80 °C
3. Humidity:0~99.9%RH

DHT11 shield:

1. Operating Voltage:3.3~5 V
2. Temperature:0 to 50 °C
3. Humidity:20%-95% RH

BMP180 Shield :

1. Power Supply:1.8~3.6 V
2. Low power Consumption:5 uA
3. Pressure Range:300-1100 hPa

1-BUTTON Shield:

1. Operating Voltage:3.5~5 V
2. Insulation Voltage: DC30V

Micro SD Shield:

1. Power Supply:5 V
2. Interface Level:3.3/5 V
3. Support Card Type: Micro SD card
4. Current:200mA(max)

Package Includes:

1 x Orange Wemos Diy Kit

Kit Includes:

1 x Protoboard

1 x DS18B20 Shield

1 x ESP8266 d1 Mini Pro

1 x 5v relay Module

1 x DHT22 Shield

1 x DHT11 Shield

1 x BMP180 Shield

1 x WS2812B RGB Shield

1 x Micro SD Shield

1 x 1-BUTTON Shield
