STANDEXMEDER Reed Switch, MK20 Series, Cylindrical, SPST-NO, 10 W, 30 Vdc, 0.5 A, 22 to 30 AT

The MK20/1-B-100W is a Reed Sensor, magnetically operated reed proximity switches in a cylindrical module, fitted with interconnect cable. The sensor should be mounted on a fixed surface with the actuating magnet on the moving surface. Used in door & window contacts, with magnetic floats for water level detection, and position sensing. Flat, bent SMD leads .-20 to 70°C Operating temperature.

Features:

1. Magnetically operated
2. Flat, bent SMD lead
3. Can be mounted on a fixed surface

Specifications:

1. Contact Rating:  10 w
2. Switching voltage: 30 v
3. Carry current: 0,5 Ampere
4. Switching Current: 0,5 Ampere
5. Sensor Resistance: 280 mΩ
6. Shock: 50g
7. Vibration: 20g

Package Includes:

1 x Reed Switch, MK20 Series, Cylindrical, SPST-NO, 10 W, 30 Vdc
