STMICROELECTRONICS BLE EXP BOARD, STM32 NUCLEO DEV BOARD

The X-NUCLEO-IDB05A2 Bluetooth low-energy expansion board is based on the BlueNRG-M0 BLE network processor module. The BlueNRG-M0 is Bluetooth v4.2 compliant, FCC and IC certified (FCC ID: S9NBNRGM0AL; IC: 8976C-BNRGM0AL). It supports simultaneous master/slave roles and can behave as a Bluetooth low-energy sensor and hub device at the same time. The BlueNRG-M0 provides a complete RF platform in a tiny form factor, with integrated radio, antenna, high frequency and LPO oscillators. The X-NUCLEO-IDB05A2 is compatible with the ST morpho (not mounted) and Arduino UNO R3 connector layout.

Attention: For additional technical specifications, please refer to the accompanying datasheet in the attachment section.

Features:

1. Bluetooth low energy expansion board based on the BlueNRG-M0 module for STM32 Nucleo
2. STM32 Nucleo expansion board based on BlueNRG-M0 Bluetooth v4.2, FCC and IC certified module
3. Embedded Bluetooth low energy protocol stack (GAP, GATT, SM, L2CAP, LL, RFPHY)

Package Includes:

1 x STMICROELECTRONICS BLE EXP BOARD, STM32 NUCLEO DEV BOARD
