Water Flow Sensor (Sea) YFDN50 Flowmeter G2 10- 200L/min 5-24V

YF-DN50  2 inch is a plastic body water flow sensor that contains a water rotor and a hall-effect sensor and is used for flow measurement for industrial applications. When the water flows through the rotor, the rotor rolls, and its speed changes with a different rate of flow. The hall-effect sensor outputs the corresponding pulse signal. The output of the flow sensor is proportional to the water flow. The more the water flowing more are the pulses.

Note: Actual image may vary in terms of Cable color.

Features:

1. Waterproof, Heat resistance, pressure resistance, cold resistance, Easy to install.
2. Flow range: 10-200 Liter per min
3. Allow compression: Water pressure 1.75 Mpa below

Package Includes:

1 x Water Flow Sensor (Sea) YFDN50 Flowmeter G2 10- 200L/min 5-24V
