ODROID-H3+ Single Board Computer

Out of stock

26,986.8330,666.85 (Including tax)
SKU: rz2435074
Processor

Intel Celeron N6005 Processor (10nm

,

Quad-Core

,

TDP 10W) H3+(N6005) : up to 3.3Ghz 4MB L2 Cache Intel UHD Graphics (24/32 EU up to 900MHz)

Networking

2 x GbE LAN ports (RJ45

,

supports 10/100/1000/2500 Mbps) Realtek RTL8125B Supports Wake-On-Lan LED indicators (Green: Link

,

Amber: Traffic

Memory

2 x DDR4 1.2V SO-DIMM slots Dual Channel

,

up to 2933 MT/s (DDR4-PC23400) Max memory capacity 64GB DDR3/DDR5 are not supported

Storage

1 x eMMC connector (bootable and selectable on BIOS) Various eMMC modules can be purchased at the Hardkernel store 2 x SATA3 6Gbps ( SATA Port-Multiplier is NOT compatible ) 1 x M.2 slot (PCIe 3.0 x 4

,

supports NGFF-2280 cards) M.2 SATA SSD is not supported

Video

1 x DisplayPort 1.2 (up to 4K@60Hz) 1 x HDMI 2.0 (up to 4K@60Hz) Dual simultaneous display support

Audio

1 x Audio out (3.5mm jack) 1 x Audio in (3.5mm jack) 1 x SPDIF out (ALC1200

,

HDA codec) * HDMI & DP have audio output too.

External I/O

2 x USB 3.0 Host ports 2 x USB 2.0 Host ports 1 x Peripheral Expansion Header (24-pin

,

2.54mm pitch) – 1 x DC 5V

,

1 x DC 3.3V

,

5 x GND – 1 x UART (TXD/RXD/RTS/CTS) – 2 x I2C (SCL/SDA) – 1 x External Power Button – HDMI CEC

,

5VA+ – 3 x USB 2.0 – All 3.3V I/O signal level

Other features

Passive Heatsink BIOS Backup Battery – Maintains system time and BIOS settings Power Button Reset Button System LEDS Indicators: – Red (PWR) – Solid light when DC power is supplied – Blue (left

,

SLEEP) – turns off only when the system enters into suspend mode – Blue (right

,

PMIC) – turns on only when the major power rails are working – Amber (SATA) – Flashes when SATA data transfers – Green (NVMe) – Flashes when NVMe data transfers Active Cooling Fan Connector (12V 4-pin

,

PWM input + TACHO output) – Active Cooling Fan is optional – Connector (4-pin

,

2.54mm pitch)

Power

DC jack : outer (ground) diameter 5.5mm

,

inner(positive) diameter 2.1mm DC 14V ~ 20V (up to 60W) – DC 15V/4A power adapter is recommended if you don’t use two 3.5“ HDDs – DC 19V/7A power adapter is recommended if you two 3.5” HDDs together Power consumption: – IDLE : ≃1..9W – CPU Stress : ≃15W – CPU+GPU Stress : ≃18W – Power-off : ≃0.25W – Suspend : ≃0.6W

Form Factor

110mm x 110mm x 47mm Approx.
